Onkyo TX-SV343

Specifications
AMPLIFIER SECTION
Power Output
USA & Canadian models:
European models:
Asian models:
Total Harmonic Distortion:
IM Distortion:
Damping Factor:
Stereo Mode
60 watts per channel, min. RMS into
8 ohms, both channels driven from
20 Hz to 20 kHz with no more than
0.08% THD.
Surround Mode
Font L/R Channels
2 x 50 W (1 kHz, 0.08%. 8 ohms)
Center Channel
50 W (1 kHz, 0.15%, 8 ohms)
Rear Channels (Rear channel only
driven)
15W+I5W C1 kHz. 0.3%. 8 ohms)
Stereo mode
3x 60 watts at 6 ohms (DIN)
Surround mode
Front L/R and Center Channels
3X 450 watts at 6 ahms (DIN)
Rear Channels (Rear channel only
driven)
15 watts + 15 watts at 6 ohms (DIN)
Stereo mode
2 X SO watts at 6 ohms. | kHz (ETAS)
Surround mode
Front L/R and Center Channels
3 & 45 watts at 6 ohms. | KHz (EIAS)
Rear Channels (Rear Channel only driven)
20 watts + 20 watts at 6 ohms, | kHz
(EIAJ)
0.08% at rated power (Front)
0.08% at rated power (Front)
60 at 8 chins (Front)
Inpul Sensitivity and Impedance
Phono: 2? 5 mV. 50 kohms
Line (CD, Tape. TV/AUX Video-1. 2):
Video (Video-1.2):
Output Level and Impedance:
Phono Overload:
Frequency Response:
RIAA Deviation:
Tone Control
Buss:
Treble:
Signal-to-Noise Ratio
Phono:
CD/Tape:
Muting:
VIDEO SECTION
Signal sensitivity and
200 mV. 50 kohms
| Vp-p. 75 ohms
Ree Out (Tape): 200 mV, 2. 2 kohms
Out (Video-?): 200 mV. 2.2 kohms
Pre Out (Subwooter): | V. 2.2 kohms
Video ( Video-2. Monitor):
| Vp-p. 75 ohms
120 mV RMS. at 1 kHz, 0.5% T.H.D.
20 Hz to 30 kHz, +] dB
20 Hz to 20 kHz, +0.8 dB
+10 dB at 100 Hz
+10 dB at 10 kHz
80 dB (IHF A. 5 mV input)
100 dB (IHF A)
$0 dB
f Vp-p. 75 ohms
TUNER SECTION
FM
Tuning Range:
U.S.A. & Canadian models:
Other areas:
Usable Sensitivity
Mono:
Stereo:
50dB Quieting Sensitivity
Mono:
Stereo:
Capture Ratio:
Image Rejection Ratio
U.S.A. & Canadian models:
Other area models:
IF Rejection Ratio:
Signal-to-Noise Ratio
Mono:
Stereo:
Alternate Channe! Attenuation
Mono:
Selectivity:
AM Suppression Ratio:
Total Harmonic Distortion
Mono:
Stereo:
Frequency Response:
Stereo Separation:
AM
Tuning Range
U.S.A. & Canadian models:
European models:
Worldwide models:
Usable Sensitivity:
Image Rejection Ratio:
IF Rejection Ratio:
Signal-to-Noise Ratio:
Total Harmonic Distortion:
GENERAL
Power Supply
U.S.A. & Canadian models:
European & Australian
models:
Woldwide models:
Power Consumption
U.S.A. & Canadian models:
Other area models:
Dimensions (W x H x D):
Weight:
87.5 — 108.0 MHz (100 kHz steps)
87.50 — 108.00 MHz (S50 kHz steps)
11.2 dBf, 1.0 pV (75 ohms IHF)
17.2 dBf, 2.0 uV (75 ohms THF)
18.2 dBt, 2.2 uV (75 ohms)
38.2 dBf. 22 wv (75 ohms)
1.5 dB
40 dB
$5 dB
90 dB
73 dB (IHF)
67 dB (IHF)
55 dB (IHF)
50 dB (DIN, +300 kHz. 40 kHz Devi.)
50 dB
0.15%
0.25%
30 Hz — 15 kHz. £1.5 dB
45 dB at | kHz
30 dB at 100 Hz — 10 kHz
530—1.710 kHz (10 kHz steps)
522—1,611 kHz (9 kHz steps)
531—1.602 kHz (9 kHz steps),
530—1.710 kHz (10 KHz steps)
30 UV
40 dB
40 dB
40 dB
0.7%
AC 120 V. 60 Hz
AC 230 V, 50 Hz
AC 230-220 V and 120 V switchable, 50/60
Hz
27A
220 W
435 x 150 x 32? mm
1 7-1/8" x 5-7/8" « 12-1 1/16"
8.2 kg, 18. ibs.
REMOTE CONTROL RC-328S
‘Fransmitter:
Signal] range:
Infrared
Approx. 5 meters. 16 ft.
impedance: (VDP/VCR input, output) Power supply: Two “AA” batteries (1.5 V x 2)
Specifications and features are subject to change without notice.
