Maintenance
Version 1.2.4 - 2022-10-2642 Translation of original instruction
S275N | S275NV
EN
S275N_S275NV_GB_5.fm
Depending on
wear
Saw arch
Changing the saw
belt
ATTENTION!
This metal band saw was designed for use with belts
of the following dimensions.
27 x 0.9 x 2480 mm
The use of other saw blades can cause inferior
sawing results.
Place the saw arch in the upper position and close
the stop cock on the hydraulic cylinder.
Remove the saw belt brush by unscrewing the
lockscrew.
Remove the protective cover of the saw belt guide.
Remove the protective cover from the saw arch.
Loosen the tension of the saw belt by turning the
hand wheel anti-clockwise.
Carefully remove the old saw belt.
Fit the new saw blade by inserting it first into the saw
belt guide.
Check the running direction and toothing.
Running direction of the saw belt on page 26
Place the saw belt on the two pulleys so that it is as
close as possible to the casing of the saw arch.
Tighten the saw belt.
Run a check as described in First commissioning
on page 25.
For fitting the components, proceed in reverse order.
Proceed a trial run.
Re-fit the protective covers.
As required
Coolant equipment
Coolant pump
The coolant pump is almost maintenance-free.
Replace at regular intervals and adapted to use the
coolant fluid and clean the inside of the pump of
chips. Not all chips can be retained by the gap filter
in the chip tray, and can therefore be sucked back in
by the pump, which can lead to destruction of the
pump.
Interval Where? What? How?
