OPTIMUM
MASCHINEN - GERMANY
Maintenance
Version 1.1.5 dated 2015-08-31 Page 39Original operating instructions
BF30Vario GB
First after 200
operatingm
hours, then
every 2000
operating
hours
Gear milling head
Oil change
For oil change use an appropriate collecting tray of suffi-
cient capacity.
Have the drilling-milling machine run for a few minutes, the
oil will heat up and will slightly penetrate from the opening.
Remove the ventilation screw from the gear.
Remove the oil drain plug.
Refill the oil over the removed ventilation screw.
Quantity and type of oil
"Operating material“ on page 18
Img.5-2: Milling head
Interval Where? What? How?
Oil drain plug
Ventilation screw of the gear
