Maintenance
Version 1.1.5 dated 2015-08-31Page 40 Original operating instructions
BF30VarioGB
Every week
Drilling-milling machine
Oiling
 Lubricate all slideways.
Img.5-3: Slideways
Every six
months
Adjustment Z axis
Lubricating
 Clamp the milling head.
 Remove the service cover from the column.
 Lubricate the gearwheels.
Img.5-4: Adjustment Z axis
Interval Where? What? How?
Slideways X axis
Slideways Y axis
Slideways Z axis
Toothed wheels feed gear
