COMPACT version 5.2.002 ENG
25
Modular audio matrix
with IP connection
COMPACT
4ETH
R + D Department
COMPONENT
GENERATING THE
ALARM
TYPE OF ALARM
DESCRIPTION
RECOVERY
"UNIT NAME"
MICROPHONE
CAPSULE ERROR
Indicates a capsule error of the
microphone desk that is sending the
alarm.
ME-200B
CAPSULE ERROR
Indicates a capsule error of the
microphone on the ME-200B front
module.
Check the connection from the
microphone to the ME-200B module
(metal DIN connector).
ME-200B
NOT DETECTED
Module ME-200B is not detected.
If the COMPACT incorporates the ME-
200B module, disconnect the power
supply and check the internal
connections between the ME-200B
module and the COMPACT.
If the COMPACT does not incorporate an
ME-200B module, disable this
functionality in the unit's web
configuration.
"NAME OF THE
CONTACT"
SHORT CT ERR.
A short-circuit is detected in the
connection of a contact configured to be
monitored.
Check the connection of the contact.
If the contact must not be monitored,
modify the configuration of the contact
via the Call Point software.
"NAME OF THE
CONTACT"
OPEN CT ERR.
An open contact is detected in the
connection of a contact configured to be
monitored.
Check the connection of the contact.
If the contact must not be monitored,
modify the configuration of the contact
via the Call Point software.
"PERSONALISED
TEXT TO NOTIFY AN
ALARM"
A contact may be configured so its
activation will generate an alarm on the
screen with the desired text.
S ["n"]
(n= Number of
slave, id.)
NOT DETECTED
The system does not detect a COMPACT-
E unit that appears in the configurations
of the installation.
Check the CAN bus connection between
the COMPACT-E unit and the COMPACT.
If the unit is not physically present, check
the configuration of the installation in
the Call Point software to verify that a
COMPACT-E unit has not been added by
error. If so, delete it.
S ["n"]
(n= Number of
slave, id.)
CONFIGURATION
ERROR
The system detects a COMPACT-E unit
that does not appear in the
configurations of the installation.
Use the Call Point software to add the
unit to the installation tree.
or
disconnect the unit from the CAN bus
C ["n":"p" ]
(n= Number of
slave, id.)
If the value is 0,
the unit is a
COMPACT)
(p= lot occupied by
the card)
NOT DETECTED
The unit "n" incorporates a card in slot
"p" that is not detected by the system,
although it does appear in the
configurations of the installation.
Check that the card is physically present
and is properly inserted
or
the card is missing. From the Call Point
software, delete the card from the
installation tree.
