Optoma HD86 - 2-2.DMD Specifications; 2-3.Color Wheel; 2-4.Lamp; 2-5.Terminal Connectors

Delta Elec. Inc. HD86
Company Confidential Optoma___________________ Delta________________
7
2009/08/18
2-2.DMD Specifications
Unit Min.
Max
.
Typical Notes
DMD type TI 0.65" 1080p 12 deg LVDS
Type A
Number of Columns Pixel 1920
Number of Rows Pixel 1080
Panel Operating Temp.
℃
10 65
Ambient Temp
℃
25
2-3.Color Wheel
Spec.
Unit Min. Max. Typical Notes
Color Segment RGBRGB
65/60/55/65/60/55 (55mm)
2-4. Lamp
Description
Vendor OSRAM
Type E20.9 280W
Standard Mode , TBD Hours Standard @ 180W, 50% Survival Rate
Lamp Life
ECO Mode , TBD Hours Typical @ 160W, 50% Survival Rate
Normal: 280W±3%@Vo from 50V to 120V
Lamp Power
ECO: 230W±3%@Vo from 50V to 120V
2-5. Terminal connectors
Input
Digital HDMI x 3
Analog RGB HD-15 x 1
Composite RCA x 1 (Yellow)
S-Video mini dim x 1
Component RCA x 3 (G/B/R)
Control
RS-232 DSUB-9 x 1
DC out (screen trigger)
DC Jack x 2 (12V±10
％
; 200mA)
Keyboard Emulation Control USB connector type B
