Optoma HD86 - 10-2.Power & READY LED Blink Code Message

Delta Elec. Inc. HD86
Company Confidential Optoma___________________ Delta________________
75
2009/08/18
10-2. Power & READY LED Blink Code Message
Power KEY /LED on IO board Layout
Keypad/LED Definition
Name Usage
POWER LED Display the power on/off sequence status
TEMP LED Display the thermal status
LAMP LED Display the lamp status
Power Power key, lamp On/Off switch
