Optoma HD86 - 11 RS-232 Command

Delta Elec. Inc. HD86
Company Confidential Optoma___________________ Delta________________
78
2009/08/18
11. RS-232 Command
HD86 RS232 Command Table.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Baud Rate : 9600
Data Bits: 8
Parity: None
Stop Bits: 1
Flow Control : None
UART16550 FIFO: Disable
Projector Return (Pass): P
Projector Return (Fail): F XX=01-99, projector's ID, XX=00 is for all projectors
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND to projector Note : There is a <CR> after all ASCII commands
0D is the HEX code for <CR> in ASCII code
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code Function Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX00 1 7E 30 30 30 30 20 31 0D Power ON
~XX00 2 7E 30 30 30 30 20 32 0D Power OFF
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX01 1 7E 30 30 30 31 20 31 0D Resync
~XX12 1 7E 30 30 31 32 20 31 0D HDMI 1
~XX12 15 7E 30 30 31 32 20 31 35 0D HDMI 2
~XX12 16 7E 30 30 31 32 20 31 36 0D HDMI 3
~XX12 14 7E 30 30 31 32 20 31 34 0D Component YPbPr
~XX12 5 7E 30 30 31 32 20 35 0D VGA
~XX12 7 7E 30 30 31 32 20 37 0D Direct Source Selection VGA SCART
~XX12 8 7E 30 30 31 32 20 38 0D VGA Component
~XX12 9 7E 30 30 31 32 20 39 0D S-video
~XX12 10 7E 30 30 31 32 20 31 30 0D Video
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX20 1 7E 30 30 32 30 20 31 0D Display Mode Cinema 1
~XX20 9 Cinema 2
~XX20 2 7E 30 30 32 30 20 32 0D Bright
~XX20 3 7E 30 30 32 30 20 33 0D Photo
~XX20 4 7E 30 30 32 30 20 34 0D Reference
~XX20 10 Graphics
~XX20 5 7E 30 30 32 30 20 35 0D User
~XX20 6 7E 30 30 32 30 20 36 0D ISFDay
~XX20 7 7E 30 30 32 30 20 37 0D ISFNight
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX21 n 7E 30 30 32 31 20 a 0D Brightness n= 0 (a=30) - +100 (a=31 30 30)
~XX22 n 7E 30 30 32 32 20 a 0D Contrast n= 0 (a=30) - +100 (a=31 30 30)
~XX23 n 7E 30 30 32 33 20 a 0D Sharpness n= 1 (a=31) - +15 (a=31 35)
~XX44 n 7E 30 30 34 34 20 a 0D Color n= 0 (a=30) - +100 (a=31 30 30)
~XX45 n 7E 30 30 34 35 20 a 0D Tint n= 0 (a=30) - +100 (a=31 30 30)
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX196 n 7E 30 30 31 39 36 20 a 0D Image/Advanced Noise Reduction n= 0 (a=30) - 10 (a=31 30)
~XX35 1 7E 30 30 33 35 20 31 0D Image/Advanced/Gamma Film
~XX182 n 7E 30 30 31 38 32 20 a 0D Curve Type n=-7 (a=2D 37) - +7 (a=37)
~XX183 n 7E 30 30 31 38 33 20 a 0D Offset n=-5 (a=2D 35) - +5 (a=35)
~XX35 2 7E 30 30 33 35 20 32 0D Video
~XX184 n 7E 30 30 31 38 34 20 a 0D Curve Type n=-7 (a=2D 37) - +7 (a=37)
~XX185 n 7E 30 30 31 38 35 20 a 0D Offset n=-5 (a=2D 35) - +5 (a=35)
~XX35 3 7E 30 30 33 35 20 33 0D Graphics
~XX186 n 7E 30 30 31 38 36 20 a 0D Curve Type n=-7 (a=2D 37) - +7 (a=37)
~XX187 n 7E 30 30 31 38 37 20 a 0D Offset n=-5 (a=2D 35) - +5 (a=35)
~XX35 4 7E 30 30 33 35 20 34 0D Standard
~XX188 n 7E 30 30 31 38 38 20 a 0D Curve Type n=-7 (a=2D 37) - +7 (a=37)
~XX189 n 7E 30 30 31 38 39 20 a 0D Offset n=-5 (a=2D 35) - +5 (a=35)
~XX41 n 7E 30 30 34 31 20 a 0D Image/Advanced/PureEngine PureDetail n=Off/1/2/3 (a=30/31/32/33)
~XX42 n 7E 30 30 34 32 20 a 0D PureColour n=Off/1/2/3/4/5 (a=30/31/32/33/34/35)
~XX190 n 7E 30 30 31 39 30 20 a 0D PureMotion n=Off/Low/Med/High (a=30/31/32/33/34)
~XX197 n 7E 30 30 31 39 37 20 a 0D Pure Demo n=Off/H Spilt/V Spilt=0/1/2 (a=30/31/32)
~XX191 n 7E 30 30 31 39 31 20 a 0D DynamicBlack n=Off/Cinema 1/Cinema 2=1(a=30/31/32)
~XX210 n 7E 30 30 33 36 20 31 0D Color Temp. D50/D65/D70/D75/D83/D93/Native n=1/2/3/4/5/6/7 (a=30/31/32/33/34/35/36)
~XX211 n Color Gamut Native/DLP/HDTV/EBU/SMPTE-C n=Off/1/2/3/4/5 (a=30/31/32/33/34/35)
