13. HD86 (HT-8601) Spare part list
HD86(HT-8601) Spare parts list
TYPE NO
DESCRIPTION
P/N Q'ty
Cover assy
1
CASE TOP ASSY HT8601 OPTOMA 3398044401
1
Cover assy
2
CASE BOTTOM ASSY HT8601 OPTOMA 3398044500
1
Cover assy
3
CASE FRONT ASSY HT8601 OPTOMA 3398044601
1
Cover 4
IO COVER PC 945VB BLK 3392109700
1
Cover 5
LAMP COVER PPS 94V0 BLK 3392109400
1
Cover 6
LENS KNOB PC 94V0 BLK 3392111600
1
Filter 7
FILTER PPS+GF 94V0 BLK 3392112400
1
Filter PU 8
FILTER PU 94VHF1 71*49.5*3.5 BLK 3243153401
1
ADJ FOOT
9
ADJ FOOT 3390704100
1
Fan1 10
DC FAN ASSY BFB0612H-SE03 L110/50 60 B 3620640411
1
Fan3 11
DC FAN ASSY NFB10512HF-SE00 L85/25 105 B
3620101011
1
Fan2 12
DC FAN ASSY AUB0812H-SE17 L130/70 80 S
3622838011
1
Board 13
PWB ASSY MAIN BOARD H7T-01-OHDME 5600601071 1
Board 14
PWB ASSY THERMAL DIODE BOARD H7T 5600601074 1
Board 15
PWB ASSY POWER BD HT-8601 5600601078 1
Board 16
PWB ASSY FORMAT BOARD H7T 5600601067 1
Board 17
PWB ASSY IRIS BOARD H7T 5600601072 1
Board 18
PWB ASSY IO BOARD H7T-01 5600601069 1
Board 19
PWB ASSY IR BOARD H7T-01 5600601070 1
Board 20
PWB ASSY INDEX BOARD 5600601068 1
Ballast 21
LAMP DRIVER 280W UNISHAPE O3 TOP 0990077900 1
C/W 22
Color Wheel HT-8601 3797706300 1
