Delta Elec. Inc. HD86
Company Confidential Optoma___________________ Delta________________
80
2009/08/18
~XX39 5 7E 30 30 33 39 20 35 0D VGA
~XX39 9 7E 30 30 33 39 20 39 0D S-Video
~XX39 10 7E 30 30 33 39 20 31 30 0D Video
~XX100 1 7E 30 30 31 30 30 20 31 0D Source Lock On
~XX100 2 7E 30 30 31 30 30 20 32 0D Off
~XX106 n 7E 30 30 31 30 36 20 a 0D Auto Power Off (min) n=0 (a=30)-60 (a=36 30) (multiple of 5)
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX73 n 7E 30 30 37 33 20 a 0D Signal Tracking (Frequency) n= 0 (a=30) –200 (a=32 30 30)
~XX74 n 7E 30 30 37 34 20 a 0D Phase n= 0 (a=30) – 100 (a=31 30 30)
~XX75 n 7E 30 30 37 35 20 a 0D H. Position n= 0 (a=30) – 100 (a=31 30 30)
~XX76 n 7E 30 30 37 36 20 a 0D V. Position n= 0 (a=30) – 100 (a=31 30 30)
~XX200 n 7E 30 30 32 30 30 20 a 0D Black Level n=0 (a=30) -100 (a=31 30 30)
~XX201 n 7E 30 30 32 30 31 20 a 0D White Level n=0 (a=30) -100 (a=31 30 30)
~XX202 n 7E 30 30 32 30 32 20 a 0D Saturation n= 0 (a=30) – 100 (a=31 30 30)
~XX203 n 7E 30 30 32 30 33 20 a 0D Hue n= 0 (a=30) – 100 (a=31 30 30)
~XX204 n 7E 30 30 32 30 34 20 a 0D IRE n=0/7.5 (a=30/31)
~XX217 1 HDMI Black Level YCbCr
~XX217 2 RGB
~XX217 3 AUTO
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
SEND from projector automatically
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code
Function Projector Return Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
when Standby/Warming/Cooling/Out of Range/Lamp fail INFOn n : 0/1/2/3/4 = Standby/Warming/Cooling/Lamp fail
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
READ from projector
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
232 ASCII Code HEX Code
Function Projector Return Description
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
~XX121 1 7E 30 30 31 32 31 20 31 0D Input Source Commands OKn n: 0/1/2/3/4/5/6/7/8
= None/HDMI 1/HDMI 2/DVI/Component/VGA/S-Video/Video
~XX122 1 7E 30 30 31 32 32 20 31 0D Software Version OKaaaa
~XX123 1 7E 30 30 31 32 33 20 31 0D Display Mode OKn n: 0/1/2/3/4/5/6
=Cinema/ Bright/ Photo/ Reference/ User/ ISFDay/ ISFNight
~XX124 1 7E 30 30 31 32 34 20 31 0D Power State OKn n: 0/1=Off/On
~XX125 1 7E 30 30 31 32 35 20 31 0D Brightness OKn
~XX126 1 7E 30 30 31 32 36 20 31 0D Contrast OKn
~XX127 1 7E 30 30 31 32 37 20 31 0D Aspect Ratio OKn n: 0/1/2/3/4
=4x3, 16x9, LBX, Native
~XX128 1 7E 30 30 31 32 38 20 31 0D Color Temperature OKn n: 0/1/2=Warm/Medium/Cold
~XX129 1 7E 30 30 31 32 39 20 31 0D Projection Mode OKn
=Front-Desktop/Rear-Desktop/Front-Ceiling/Rear-Ceiling
~XX150 1 7E 30 30 31 35 30 20 31 0D Information OKabbbbcdddde a : 0/1=Off/On
bbbb: Lamp Hour
c: source 0/1/2/3/4
= None/HDMI 1/HDMI 2/DVI/Component/VGA/S-Video/Video
dddd: FW version
e : Display mode 0/1/2/3/4/5
=Cinema/ Bright/ Photo/ Reference/ User
~XX151 1 7E 30 30 31 35 31 20 31 0D Model Name OKn n : 0/1/2=HD82/HD82LV
~XX152 1 7E 30 30 31 35 32 20 31 0D RS232 Version No OKn
