Optoma L1 User Manual

English
35
USING THE PROJECTOR
Image wall color menu
Designed to adjust the colors of the projected image when projecting on to a wall without a screen. Each mode has
been ne-tuned by our expert colour team to ensure superior color performance.
There are several predened modes that you can choose from to suit the colour of your wall. Select between o󰀨,
blackboard, light yellow, light green, light blue, pink, and grey.
Note: For accurate color reproduction, we recommend using a screen.
Image 3D menu
Note:
 This projector is a 3D ready projector with DLP-Link 3D solution.
 Please make sure your 3D glasses are use for DLP-Link 3D before enjoy your video.
 This projector supports frame sequential (page-ip) 3D via HDMI1/HDMI2 ports.
 To enable 3D mode, the input frame rate should be set to 60Hz only, lower or higher frame rate is not
supported.
 To reach the best performance, resolution 1920x1080 is recommended, please be noted that 4K
(3840x2160) resolution is not supported in 3D mode.
3D Mode
Use this option to disable or enable the 3D function.
 O󰀨: Select “O󰀨” to turn o󰀨 3D mode.
 On: Select “On” to turn on 3D mode.
3D Sync Type
Use this option to select 3D technology.
 DLP-Link: Select to use optimized settings for DLP 3D Glasses.
 3D Sync: Select to use optimized settings for IR, RF or polarized 3D Glasses.
3D Format
Use this option to select the appropriate 3D format content.
 Auto: When a 3D identication signal is detected, the 3D format is selected automatically.
 SBS: Display 3D signal in “Side-by-Side” format.
 Top and Bottom: Display 3D signal in “Top and Bottom” format.
 Frame Sequential: Display 3D signal in “Frame Sequential” format.
3D Sync Invert
Use this option to enable/disable the 3D sync invert function.
Reset
Return the factory default setting for 3D settings.
 No: Select to cancel Reset.
 Yes: Select to return the factory default settings for 3D.
Image reset menu
Return the factory default settings for image settings.

Optoma L1 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	0.47 - 0.74 m
Vertical scan range	50 - 240 Hz
Projection technology	DLP
Contrast ratio (typical)	1800000:1
Screen size compatibility	75 - 120 \
Projector native resolution	2160p (3840x2160)
Keystone correction, horizontal	10 °
Projector brightness (economic mode)	1050 ANSI lumens
Lamps quantity	1 lamp(s)
Light source type	LED
Service life of light source	30000 h
Focus	Auto/Manual
Offset	126 %
Throw ratio	0.25:1
Fixed focal length	2.63 mm
Analog signal format system	-
DVI port	No
Audio (L/R) out	1
HDMI connector type	Full-size
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
Noise level	28 dB
Preset modes	Game
Number of OSD languages	25
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FAS, FIN, FRE, GRE, HUN, IND, ITA, JPN, NOR, POL, POR, RUM, RUS, SWE, TUR, VIE
RMS rated power	20 W
Number of built-in speakers	2
Placement	Desktop
Product type	Ultra short throw projector
Product color	Black
Market positioning	Home cinema
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50-60 Hz
Power consumption (max)	165 W
Power consumption (standby)	0.5 W
Power consumption (typical)	98 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %

Weight and Dimensions

Depth	316 mm
Width	400 mm
Height	102.3 mm
Weight	5100 g
Package weight	7800 g
