S310e/X312
Condential 2-9
1. Unscrew 8 M2.6*8 screws (as blue circle)
2. Unscrew 4 H4*L8 hex screws (as
green circle) and 1 M2.6*8 screw to
disassemble IO cover .
3. Remove IO cover
