MICROS Compact Workstation 310 Technical Specifications
The following table contains the technical specifications for the Compact Workstation
310.
Table 2-1 Technical Specifications for the Oracle MICROS Compact
Workstation 310
Feature 310 310R
Processor Intel Atom x5-E3930 Processor @ 1.30GHz, 2C/2T, 2M
Cache, (Apollo Lake)
Display 10.1 inches, 16:10 WXGA,
1280(H) x800(V), 262k colors
(RGB 6-bits), brightness= 300
Nits
10.1 inches, 16:10 WXGA,
1280(H) x800(V), 262k colors
(RGB 6-bits) brightness= 800
Nits
Customer Display 256 x 64 Graphical OLED Display
Touchscreen Projected capacitive touchscreen with 10-point simultaneous
touch
Memory 4GB DDR3L @ 1600 MHz standard (8GB MAX)
Storage 64GB eMMC v5.0, 400MB/sec MAX. Non-removable.
Operating System Microsoft Windows 10 IoT Enterprise (64-bit only)
Magnetic Card Reader 3 track, encryption-capable with Merchantlink encryption key
pre-injected
Network 10/100/1G Ethernet, optional WiFi w/ Bluetooth
USB 5 Total:
• 2 USB 2.0 on I/O Panel (+5V @ 0.5A / 2.5W)
• 2 USB on I/O Panel (+5V @ 09A / 4.5W)
• 1 USB on I/O Panel (+5V/+15V @ 3.0A)
Serial Ports 2 Total:
• 1 - RJ45 RS422/RS232 IDN
• 1 - RJ45 RS232
Cash Drawer Ports 2 Total. For use with Series 2 Cash Drawers. Dongle available
to convert Series 1 Cash Drawers to Series 2.
Power Supply External brick, 15V@5.33A (80W), 80~264VAC input. Optional
battery power pack available.
Weight Workstation only: 3.64 lbs. Workstation with Flexible stand =
9.0 lbs.
Dimensions 7.5 x 11.6 x 1.9 in / 191 x 294 x 47mm
Operating Temperature 0-50C (32-122F) -10-60C (14–140F)
Resistance to Spills and
Debris
IP43 for Compact Workstation
310, IEC/EN 60529-22
IP45 for Compact Workstation
310R, IEC/EN 60529-22
Impact Resistance EN62262–IK07: Impact energy= 2.0 joules
Chapter 2
MICROS Compact Workstation 310 Technical Specifications
2-2
