Table 5-1 (Cont.) MICROS Tablet E-Series with MSR Sleeve Features
Feature E-Series 8 w/ Sleeve E-Series 11 w/ Sleeve
External Connectors &
Controls /w MSR Sleeve
• Micro USB (charging
only)
• Headphone/Microphone
Jack
• Volume Up/Down
• Power/Standby Button
• Gang Charger Pins
• Scanner Trigger Button
(Optional Scanner)
• Micro USB (charging
only)
• Headphone/Microphone
Jack
• Volume Up/Down
• Power/Standby Button
• Gang Charger Pins
• Multi-Function Docking
Connector for Base
Station
Network 802.11 a/b/g/n Dual Band Wi-
Fi with WPA, WPA2, TKIP,
AES support
Bluetooth 4.0
802.11 a/b/g/n Dual Band Wi-
Fi with WPA, WPA2, TKIP,
AES support
Bluetooth 4.0
Card Reader Micro SD (SD, SDHC, SDXC -
64GB max)
Micro SD (SD, SDHC, SDXC -
64GB max)
Battery 2-Cell Lithium-Ion 18Wh 2-Cell Lithium-Ion 32Wh
Operating Temperature 0°C (32°F) to 35°C (95°F) 0°C (32°F) to 40°C (104°F)
Storage Temperature -10°C (14°F) to 45°C (113°F) -10°C (14°F) to 45°C (113°F)
Weight 400g (0.88lb) 726g (1.7lb)
Dimensions Length: 216mm (8.51 inches)
Width: 130mm (5.11 inches)
Thickness: 9 mm (0.35 inches)
Length: 280mm (11.02 inches)
Width: 177mm (6.97 inches)
Thickness: 10.2 mm (0.40
inches)
Certifications FCC Class A, UL, CE, TUV,
RoHS, China RoHS
FCC Class A, UL, CE, TUV,
RoHS, China RoHS
MICROS Tablet E-Series 8 with MSR Sleeve Connectors
The figures below display front and back views of the MICROS Tablet E-Series 8 and
E-Series 11 along with their respective MSR Sleeve.
Chapter 5
MICROS Tablet E-Series 8 with MSR Sleeve Connectors
5-3
