Oracle MICROS Workstation 5A User Manual

Table 9-1 (Cont.) PC Workstation 2015 Features
Features Specifications
Case Style Standard Low Profile or Optional Adjustable Stand
Case Material PC-ABS Plastic
Weight 13.2 lbs. (6.0 kg), Shipping Weight 17.6 lbs. (7.9 kg)
Physical Dimensions See Appendix A
Optional Customer
Displays (Series 1)
Integrated or Pole 240x64 STN Graphics LCD Integrated or Pole
Protégé Customer Display System
Cash Drawers 2 MICROS 4-Pin DIN Connectors - +12V or +24V selectable in BIOS.
COM Ports • 1 DB9 RS232 Serial (COM1 - Powered (5V, 9V, or 12V -
Selectable in BIOS)
• 1 DB9 RS232 Serial (COM2 - Non Powered)
• 1 Modular RS232 (COM5)
• 1 Combination RS232/RS422 (COM4)
USB Ports Four USB 2.0 Ports
Powered USB Ports • Two MICROS Powered USB Ports
• USB5 (+5V, +12V, +24V) - USB6 (+5V, +12V)
LAN Interface 10/100/1000 Mbps Ethernet - RJ45
AC Input Voltage Universal Input - 85 to 264VAC, 47 to 63Hz.
Input Power 35W Typical
BTU/Hour 120 Typical, 290 Maximum
Operating
Temperature
0°C (32°F) to 45°C (113°F), 90% relative humidity max.
Storage Temperature -25°C (-13°F) to 80°C (176°F)
MICROS PC Workstation 2015 Connectors
The figure below shows the PC Workstation 2015 Modular COM ports.
Figure 9-2 PC Workstation 2015 I/O Panel Modular Connectors
Chapter 9
MICROS PC Workstation 2015 Connectors
9-2
