Table 13-1 (Cont.) MICROS Workstation 4 LX Features
Feature Specifications
Weight 7.7 lbs. (3.5 kg) / Shipping Weight 11 lbs. (5
kg)
Physical Dimensions The Equipment Dimensions for the
Workstation 4 LX section contains more
information.
Optional Customer Displays (Series 1) Integrated or Pole 240x64 STN Graphics
Capable LCD Integrated or Pole Protégé
Customer Display System
Cash Drawers 2 MICROS 4-Pin DIN Connectors - +12V or
+24V selectable in the BIOS.
COM Ports • 1 DB9 RS232
• 1 Modular RS232
• 2 Combination RS232/RS422
USB Ports 4
LAN Interface On Board Mbps 10/100/1000 - RJ45
Input Voltage Universal Input - 85 to 264VAC, 47 to 63Hz.
Input Power 23W Typical, 65W Max
BTU/Hour 80 Typical, 222 Maximum
Operating Temperature 0°C (32°F) to 45°C (113°F), 90% relative
humidity max.
Storage Temperature -24°C (-13°F) to 80°C (176°F)
MICROS Workstation 4 LX Connectors
The figure below shows the Workstation 4 LX Modular COM ports.
Figure 13-2 Workstation 4 LX I/O Panel Modular Connectors
Chapter 13
MICROS Workstation 4 LX Connectors
13-2
