Table 6-1 (Cont.) MICROS Tablet R-Series Features
Feature Specifications
Display 10.1” WVGA (1024x600) TFT LCD /w LED
Backlights Portrait or Landscape orientation
and Auto-Rotation
Two LCD options are available:
• Standard 10.1” LED backlit TFT LCD
• Daylight readable TFT based on adaptive
LCD technology.
Operating System Windows Embedded Compact 7
Touchscreen Truly Projected Capacitive Touch Sensor that
supports multi-touch and gesturing
Memory 1GB DDR3 SDRAM
Storage 4G Fixed NAND Flash
8G microSD Flash Card
Backlight LED backlights with three intensity setting
controlled by the Automatic Light Sensor or
API
Case Material Magnesium Alloy, PC-ABD, and Nylon
materials
Spill and drop resistant
Weight 830 grams (1.8 lbs.)
Physical Dimensions 16mm D, 176mm W, 292mm H (0.62 in x 6.90
in x 11.5 in)
Mag Stripe Reader Modular Integrated 3-Track card reader
capable of encryption at the swipe.
Ports Charging Pins (for MICROS Tablet Multi-Unit
Charger)
Multi-function connector for Base Station (All
signals between Tablet and Base Station)
Network 802.11 a/b/g/n Wi-Fi with WPA WPA2, TKIP,
AES support
Bluetooth V2.01
Wi-Fi/Bluetooth not available on Concessions
Tablet
Battery Embedded Lithium Ion (21.8Wh)
Embedded Battery not available on
Concessions Tablet
Input Power 5 VDC, 2.5A
BTU/Hour 120 Typical, 290 Maximum
Operating Temperature -10°C (14°F) to 60°C (140°F)
When Charging Battery: 0°C (32°F) to 45°C
(113°F)
Storage Temperature -25°C (-13°F) to 85°C (185°F)
Certifications FCC Class A, UL, CE, TUV, RoHS, China
RoHS
Chapter 6
MICROS Tablet R-Series Features
6-2
