Table 7-1 (Cont.) MICROS Base Station Features
Feature Specifications
USB Ports • 2 USB 2.0
• 2 USB
• 1 MICROS Powered USB
Network 10/100/1000 Mbps Ethernet - RJ45
Battery 79Wh Lithium Ion Smart Battery
Input Power 25 Watts
AC Input Voltage Universal Input - 85 to 264VAC, 47 to 63Hz.
BTU/Hour 120 Typical, 290 Maximum
Operating Temperature -10°C (14°F) to 60°C (140°F)
When Charging Battery: 0°C (32°F) to 45°C
(113°F)
Storage Temperature Without Battery: -25°C (-13°F) to 80°C (176°F)
With Battery: -20°C (-4°F) to 60°C (140°F)
Certifications FCC Class A, UL, CE, TUV, RoHS, China
RoHS
MICROS Base Station Connectors
The figure below shows the Base Station Modular COM ports and 8-Pin Mini-DIN
Cash Drawer connectors.
Figure 7-3 Base Station Modular and Smart Cash Drawer Connectors
The Cash Drawer Conversion Cable, PN 300290-020-PT, adapts a MICROS Cash
Drawer with 4-pin DIN connector to Base Station.
Chapter 7
MICROS Base Station Connectors
7-3
