Table 10-1 (Cont.) MICROS PC Workstation 2010
Feature Specifications
Case Material PC-ABS Plastic
Weight (/w Hard Disk and VFD Display) With 12.1” LCD - 17 lbs. (7.7 Kg)
With 15 LCD - 22.7 lbs. (10.3 Kg)
Physical Dimensions The Equipment Dimensions section contains
more information.
Optional Customer Displays (Series) Pole 240x64 Graphics Capable Display with
2x20 emulation.
Cash Drawers 2 MICROS 4-Pin DIN Connectors - +12V or
+24V Jumper Selectable.
LAN Interface 10/100 Mbps BaseT Ethernet
COM Ports • 1 DB9 RS232 Serial
• 2 Modular RS232/RS422
USB Ports 4
AC Input Voltage Universal 90-264VAC, 47-63GHz.
Input Power 46W Typical, 242W Maximum
Operating Temperature 0°C (32°F) to 45°C (113°F), 90% relative
humidity max.
Storage Temperature -25°C (-13°F) to 80°C (176°F)
MICROS PC Workstation 2010 Connectors
The figure below shows the PC Workstation 2010 modular COM ports.
Figure 10-2 MICROS PC Workstation 2010 Connectors
Chapter 10
MICROS PC Workstation 2010 Connectors
10-2
