Oracle MICROS Workstation 5A User Manual

Table 11-1 (Cont.) MICROS Workstation 5A Features
Features Specifications
Weight 10.5 lbs. (4.7 kg) / Shipping Weight 14.0 lbs.
(6.35 kg)
Physical Dimensions The Equipment Dimensions section contains
more information.
Optional Customer Displays (Series 1) Integrated or Pole 240x64 STN Graphics
Capable LCD
Integrated or Pole Protégé Customer Display
System
Cash Drawers 2 MICROS 4-Pin DIN Connectors - +12V or
+24V selectable in BIOS
COM Ports • 1 DB9 RS232 (COM1 - Non Powered)
• 1Combination RS232/RS422 (COM4)
• 2 Modular RS232 (COM2, COM5)
USB Ports Four IO Panel USB 2.0 Ports (can be
disabled)
Powered USB Ports One MICROS Powered USB Port (+5V, +12V,
+24V)
LAN Interface On Board 10/100/1000 Mbps Ethernet - RJ45
AC Input Voltage Universal Input - 85 to 264VAC, 47 to 63Hz.
Input Power 24W Typical
BTU/Hour 83 Typical
Operating Temperature 0°C (32°F) to 45°C (113°F), 90% relative
humidity max.
Storage Temperature -25°C (-13°F) to 80°C (176°F)
MICROS Workstation 5A Connectors
The figure below shows the Workstation 5A Modular COM ports.
Figure 11-1 Workstation 5A I/O Panel Modular Connectors
Chapter 11
MICROS Workstation 5A Connectors
11-2
