Oracle MICROS Workstation 5A User Manual

Table 12-1 (Cont.) MICROS Workstation 5 Features
Feature Specifications
Physical Dimensions The Workstation 5 and 5A Equipment
Dimensions section contains more information.
Optional Customer Displays (Series 1) Integrated or Pole 240x64 STN Graphics
Capable LCD
Integrated or Pole Protégé Customer Display
System
Cash Drawers 2 MICROS 4-Pin DIN Connectors - +12V or
+24V available
COM Ports • 1 DB9 RS232
• 2 Combination RS232/RS422
USB Ports 4
LAN Interface 10/100/1000 Mbps Ethernet - Modular RJ45
AC Input Voltage Universal Input - 85 to 264VAC, 47 to 63Hz
Input Power 24W Typical
BTU/Hour 83 Typical
Operating Temperature 0°C (32°F) to 45°C (113°F), 90% relative
humidity max.
Storage Temperature -24°C (-13°F) to 80°C (176°F)
MICROS Workstation 5 Connectors
The figure below shows the Workstation 5 Modular COM ports
Figure 12-2 Workstation 5 I/O Panel Modular Connectors
Chapter 12
MICROS Workstation 5 Connectors
12-2
