4
UM0972080 A 03
Check with Orlaco which language versions are available. This manual
contains user instructions. Used photographs and illustrations give
general information and may dier from the products you use.
Contact your Orlaco dealer if you have questions, additional information,
or want to make changes that are not described in this manual.
The camera and monitor systems from Orlaco comply with the
latest CE, ADR, EMC and mirror-directive regulations.
All products are manufactured in accordance with the ISO 9001 quality
management, IATF16949 quality automotive and ISO 14001 environ-
mental management.
For installation Orlaco Monitor 7” RLED see Manual IM0973270.
For installation Orlaco Monitor 7” LEDD see Manual IM0973260.
Used abbreviations
ABC = Auto Backlight Control
AFZ = Auto Focus Zoom
AGC = Automatic Gain Control
BHO = Black Hot
CCC = Compact Color Camera
LUT = Look Up Table
DDE = Digital Detail Enhancement
FFC = Flat Field Correction
FUS = Fusion
I&F = Ice and Fire
NTS = NTSC
OSD = On Screen Display
PTZ = Pan & Tilt Zoom
RB = Rainbow
Stndrd = Std = Standard
TIC = Thermal Image Camera
WHO = White Hot
ZOO = Zoom
Introduction
Monitor 7” RLED
