Controls and Indicators
MX-55 Operation Manual
[5J VU metelS
Each back- l it VU meter incorporates a PEAK indicator which
illuminates when the signal reaches a level equivalent to
1040 IlWb/m.
[6J REF FLUX LO W/MID/H I SH
ind i catolS
[7J EQU ALIZA T ION IE C /NAB
in d /catolS
[BJ INP UT lellel control
[9J OUT PUT leve l contro l
[10J INPUT SRL switch & Indicator
[11J OUTPUT SRL switch & indicator
These indicators show the selected reference flux level. The
selection of reference flux level is made with the REF FLUX
LOW/MID/HIGH switch on the Connector Panel and each sw i rtch
position correspond ls to following flux level.
USA EURO
HIGH = 370 nWb/m HIGH = 510 nWb/m
MID = 250 nWb/m MID = 320 nWb/m
LOW = 185 nWb/m
LOW = 250 nWb/m
For information r egarding selection of USNEURO t lux I' evel settings,
refer to S ec tion 5.3.1.7.
These ind ic ators show tl he selected equalization. Selection of
eq u alization is made with the EQUALIZA T ION IEC/NAB switch
located on the Connector Panel.
These controls adjust the line input and output levels. When the
SRL button associated with an INPUT or OUTPUT control is
pressed, and its indicator illuminated, the level control has no
affect.
If the L evel control does not have enough rafilge of adjustment,
change the setting of the LINE LEVEL LOW/HIGH switch and
perform the level matching adjustment described in Section 4.3.
When one of these switches are pressed , the 0 VU indication on the
corresponding
'
VU meter corresponds to the reference flux level
selected l by the REF FLUX LOW/MID/HIGH switch.
2·14
March 1989
