8. Technical Specifications
General Technical Specifications
Display
Display Type 8" Colored LCD (Liquid Crystal Display)
Display Resolution 800 (Horizontal) × 600 (Vertical) Pixels
Display Colors 65536 colors, TFT screen
Output of the Probe Compensator
Output Voltage
(Typical )
About 5V, with the Peak-to-Peak voltage ≥1MΩ.
Frequency (Typical ) Square wave of 1KHz
Power
Mains Voltage 100～240 VAC RMS, 50/60Hz, CAT II
Power Consumption < 15W
Fuse 2A, T grade, 250V
Environment
Temperature
Working temperature: 0 ℃～ 40 ℃
Storage temperature: -20 ℃～ 60 ℃
Relative Humidity ≤ 90%
Height
Operating: 3,000 m
Non-operating: 15,000 m
Cooling Method Natural convection
Mechanical Specifications
Dimension 348mm× 170mm×78mm (L*H*W)
Weight About 1.5 kg
Interval Period of Adjustment:
One year is recommended for the calibration interval period.
84
