SECTION 4 OPERATION
Pacific Power Source ©2013 4-33 Document # 126050-10 Rev E
PORT
PIN
MNEMONIC
DESCRIPTION
COM A
2
RXDA
RECEIVE DATA PORT A
3
TXDA
TRANSMIT DATA PORT A
4
CTSA
CLEAR TO SEND PORT A
20
DCDA
DATA CARRIER DETECT PORT A
8
DSRA
DATA SET READY PORT A
5
RTSA
REQUEST TO SEND PORT A
7
GRD
GROUND PORT A
COM B
4
RTSB
REQUEST TO SEND PORT B
20
DTRB
DATA TERMINAL READY PORT B
2
TXDB
TRANSMIT DATA PORT B
3
RXDB
RECEIVE DATA PORT B
8
DCDB
DATA CARRIER DETECT PORT B
5
CTSB
CLEAR TO SEND PORT B
7
GRD
GROUND
TABLE 4.6.2 SERIAL I/O CONNECTIONS
With the serial port, it is possible to obtain all Front Panel Display information
described in section 4.3.1.
This paragraph provides the syntax and a brief description of all MS recognized
commands. Section 4.3.1 should be reviewed for detailed descriptions of
returned messages.
