SERIAL PORT COMMAND SET
Command
Command Type
Information Type
I1 <RET>
Input Screen #1
VLN, VLL, Amps, kW, kVA, Frequency,
Input NORMAL OR ABNORMAL.
O1 <RET>
Output Screen #1
CABINET VLN, VLL, Amps, kW, kVA,
Frequency, Efficiency.
O2 <RET>
Output Screen #2
CABINET VLN, VLL, %Peak Current,
%kVA, %kW, Frequency.
O3 <RET>
Output Screen #3
SYSTEM VLN, VLL, Amps, kW, kVA,
Frequency.
O4 <RET>
Output Screen #4
REMOTE VLN, VLL, Amps, kW, kVA,
Frequency.
S <RET>
Status Screen
Varies
D1 <RET>
Diag. Screen #1
Cause of Emergency Off.
D2 <RET>
Diag. Screen #2
Temperature Data
D3 <RET>
Diag. Screen #3
Internal Voltages
D4 <RET>
Diag. Screen #4
Binary Ports 2-5
H <RET>
Help Screen
Varies
ST <RET>
Reset Display CPU
<Same as pressing Input Status and Help
keys>
Q <RET>
Alarm Silence
<Same as Alarm Key>
R <RET>
Continuously Repeat Last Command.
Use <SPACE BAR> <RET> to stop.
