Packo RM/IB Series - Milk Cooling Tank Specifications; General Tank Specifications

14/78 06/02/2008
1.00
About your milk cooling tank
General specifications
The average sound level of the tank (excl. cooling unit) in the working area is less than 70 dBa.
Electrical connections:
- Tank: 200 – 240V / 50-60 Hz nominal
No harmonic interferences
- Condensing unit: - Single-phase : 230 V / 50-60 Hz nominal
- Three-phase: 3 x 400 V / 50-60 Hz nominal (3Ph+N)
A protection against low voltage must be installed
Ambient conditions : ambient temperature :
- The tank is operational between -10°C and + 50°C
- The tank can be stored between -20°C and + 70°C
On the tank a fabrication plate is installed on which you find the following information :
1
2
3
17
16
15
4
5
6
7
8
9
10
11
14 13 12
