The IB cooling system
The IB cooling system
IB cooling (=Ice Bank cooling) is achieved by spraying ice water on the outer walls of the inner tank (the
milk tank itself). This is a fast and efficient way of cooling.
As the stock of ice water does not have direct contact with the milk tank, the milk, even in small quantities,
does not freeze.
Diagram
The diagrams below represent the IB cooling system schematically:
Figure 1
Figure 2 a b
c
d
e
1 2 3 4
5
6
7
8
11 10 9
