Table for levelling VM/DX
Introduction
The table for levelling your VM/DX milk cooling tank can be found below. In the chapter
"Levelling the tank", you can find how to use the table.
Figure
LR = measuring rod length
LC = inside dimensions milk tank
L = distance between mounting studs of the dipsticks
Table
Type
H2-H1 (mm)
LR (mm)
LC (mm)
L (mm)
325
0
525
0
504
1147
1130
680
0
670
1147
1130
830
0
820
1147
1130
1000
0
670
1400
1383
1200
0
820
1400
1383
1500
0
1800
0
2000
0
Type = nominal contents of the tank.
