Packo RM/IB Series - Supply Cable

60/78 06/02/2008
1.00
Type
Type
P (Watt)/class
I max (A)/class
120
23144
45,50
160
29548
56,50
320
63688
109,80
IBR (low)
40
8696
19,50
60
12442
26,50
90
13034
27,50
120
23144
45,50
135
27461
49,50
IBR
(compact)
5
282
5,00
7.5
377
5,50
12
373
6,00
16
713
7,50
ATTENTION: REM/DIB, LS/DIB, LEM/DIB and LS/DIB (single-phase connection). The power and
the intensity are only for the tank, so without the ice-builder and its cooling group.
Supply cable
Hereafter the types of cables, to be used in function of the main fuse:
I max
A
cable
Main fuse (circuit breaker)
A
n x (mm²)
< 10
4x1,5+1,5
16
10-20
4x2,5+2,5
20
20-25
4x4+4
25
25-35
4x6+6
40
35-50
4x10+10
50
50-63
4x16+16
63
63-80
4x25+25
80
80-100
4x35+35
100
100-125
4x50+50
125
125-160
4x70+70
160
Always us a safety fuse, type "AM".
