Control Reference Guide: I/O Connectors
23
Control Reference Guide
• When recording 720p with an HD
reference or no reference input, the
recorded phase may be shifted from the
input signal.
• When the SETUP - SYSTEM - FREQUENCY
menu setting is 59-23 or 60-24, the HD
reference signal can only synchronize
playback.
5. VIDEO OUT jack
Provides analog composite video signal
output.
No signal is output when the SETUP -
SYSTEM - FREQUENCY menu setting is
24 Hz or 60-24.
In both 3D REC/PB and SYNC PB modes, the
sync signal output here is exclusively for use
by another AG-HPD24.
(
➝ “3D Signal Recording and Playback”
page 38,
➝ “Synchronous Playback” page
48)
6. HD/SD-SDI IN/OUT jacks
These provide input and output of serial
digital component audio/video signals.
◆ NOTE:
• Use 5C-FB or equivalent double-shielded
cable for connections.
7. HDMI OUT port
Connects to a monitor or TV using an HDMI
cable. In 3D REC/PB and SYNC PB modes,
3D video can be displayed by connecting a
3D monitor.
(➝ “3D Signal Recording and Playback”
page 38
, ➝ “Synchronous Playback” page
48
)
◆ NOTE:
• This machine does not support VIERA link.
Connecting it to a VIERA link compatible
device with an HDMI cable may cause
VIERA link to malfunction on that device.
8. REMOTE connector
Connect to an external controller to remotely
control the unit.
◆ NOTE:
• Use double-shielded cable for
connections.
9. LINK(D) connector
Use this connector to link two units for 3D
REC/PB and SYNC PB modes.
(
➝ “3D Signal Recording and Playback”
page 38,
➝ “Synchronous Playback” page
48)
◆ NOTE:
• Use a double-shielded RS-422A cable not
longer than 1 m long for connection.
10.KEYBOARD port (USB 2.0 Type A)
Connect an external USB keyboard to enter
meta data.
(➝ “Using a Keyboard” Vol. 2, page 80)
11.LINK(M) port (USB 2.0 Type A)
(
➝ “3D Signal Recording and Playback”
page 38,
➝ “Synchronous Playback” page
48)
◆ NOTE:
• Use double-shielded cable for
connections.
12.USB2.0 device/LINK(S) port (Type B)
(
➝ “USB Device” page 37, ➝ “3D Signal
Recording and Playback” page 38,
➝
“Synchronous Playback” page 48)
◆ NOTE:
• Use double-shielded cable for
connections.
13.Battery latch release button
(➝ “Using a battery” page 25)
14.Power supply/battery mounting location
(➝ “Power Preparations” page 25)
