Specifications:
DIGITAL AUDIO
AUDIO INPUT
AUDIO OUTPUT
AUDIO
Sampling frequency: 48 kHz (synchronized with video)
Quantization: 16 bits (DVCPRO HD/DVCPRO50/DVCPRO/DV)
16/24 bits selectabgle (AVC-Intra 100/AVC-Intra 50)
Headroom: 12/18/20 dB (selectable)
De-emphasis: T1=50 µs, T2=15 µs (auto on/off)
Analog inputs (CH1, CH2): XLR × 2
SDI input: BNC × 1
SDI output: BNC × 1
Monitor outputs: Pin jacks × 2, –10 dBV, 600 Ω
Headphone output: Stereo mini jack (3.5 mm dia.), 8 Ω, variable level
HDMI outputs: 2 channels (linear PCM)
Internal speaker: Round, × 1 (monaural)
OTHER I/O
Time code input: BNC × 1, 0.5 V[p-p] to 8.0 V[p-p], 10 kΩ
Time code output: BNC × 1, low impedance, 2.0 V ±0.5 V[p-p]
RS-422A I/O: 9-pin D-SUB × 1, RS-422A interface
USB HOST: USB 3.0 (Type A) × 1
Connection for USB devices/3D REC/
PB mode/SYNC PB mode:
USB 2.0 Device (Type B) × 1
For 3D REC/PB mode/SYNC PB mode
connection:
9-pin D-SUB × 1, RS-422A interface
For keyboard: USB 2.0 (Type A) × 1 (100 mA maximum)
◆ NOTE:
• This port is intended for keyboard connection.
If the keyboard draws more than 100 mA, a protective
circuit may shut down the machine.
