Output format – Format that can be output from the SDI OUT terminal [X2]
239
Format that can be output from the SDI OUT terminal [X2]
The format that can be output from the <SDI OUT> terminal differs with following combination of the settings.
• [SYSTEM] menu ¨ [FREQUENCY]
• [SYSTEM] menu ¨ [REC FORMAT]
• [VIDEO OUT/LCD/VF] menu ¨ [VIDEO OUT SEL] ¨ [SDI OUT FORMAT]
Set to the following settings in the menus when outputting only to the <SDI OUT> terminal.
•
[VIDEO OUT/LCD/VF] menu ¨ [VIDEO OUT SEL] ¨ [SDI + HDMI OUTPUT] ¨ [OFF]
• [VIDEO OUT/LCD/VF] menu ¨ [VIDEO OUT SEL] ¨ [EXTERNAL OUT SEL] ¨ [SDI]
It is also possible to output to both the <SDI OUT> terminal and the <HDMI> terminal. (ÎNote regarding simultaneous output to
the SDI OUT terminal and the HDMI terminal [X2]: 242)
 When the [FREQUENCY] is set to [59.94Hz]
 When the [FREQUENCY] is set to [50.00Hz]
* Factory setting
[REC FORMAT]
[SDI OUT FORMAT]: Output Format
Resolution Frame rate
3840×2160 59.94p [1920×1080p]: 1920×1080/59.94p 4:2:2 10 bit
[1920×1080i]
*
: 1920×1080/59.94i 4:2:2 10 bit
29.97p [1920×1080p]: 1920×1080/29.97p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/29.97PsF 4:2:2 10 bit
23.98p [1920×1080p]: 1920×1080/23.98p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/23.98PsF 4:2:2 10 bit
1920×1080 59.94p [1920×1080p]: 1920×1080/59.94p 4:2:2 10 bit
[1920×1080i]
*
: 1920×1080/59.94i 4:2:2 10 bit
59.94i [1920×1080i]: 1920×1080/59.94i 4:2:2 10 bit
29.97p [1920×1080p]: 1920×1080/29.97p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/29.97PsF 4:2:2 10 bit
23.98p [1920×1080p]: 1920×1080/23.98p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/23.98PsF 4:2:2 10 bit
1280×720 59.94p [1280×720p]: 1280×720/59.94p 4:2:2 10 bit
[REC FORMAT]
[SDI OUT FORMAT]: Output Format
Resolution Frame rate
3840×2160 50.00p [1920×1080p]: 1920×1080/50.00p 4:2:2 10 bit
[1920×1080i]
*
: 1920×1080/50.00i 4:2:2 10 bit
25.00p [1920×1080p]: 1920×1080/25.00p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/25.00PsF 4:2:2 10 bit
1920×1080 50.00p [1920×1080p]: 1920×1080/50.00p 4:2:2 10 bit
[1920×1080i]
*
: 1920×1080/50.00i 4:2:2 10 bit
50.00i [1920×1080i]: 1920×1080/50.00i 4:2:2 10 bit
25.00p [1920×1080p]: 1920×1080/25.00p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/25.00PsF 4:2:2 10 bit
1280×720 50.00p [1280×720p]: 1280×720/50.00p 4:2:2 10 bit
• The 3840×2160 output is not supported.
• User bits are not displayed.
• [SDI OUT FORMAT] restores the factory settings when the settings of [FREQUENCY] and [REC FORMAT] change and the
current setting values of [SDI OUT FORMAT] cannot be acquired.
• The output format when playing back from the thumbnail screen is as follows.
– It will be the value set in [SDI OUT FORMAT] when the recording resolution of the playback clip is the same as [REC
FORMAT].
– It will be factory setting of [SDI OUT FORMAT] when the recording resolution of the playback clip is different from [REC
FORMAT].
• There may be a fews seconds of images not displayed on the external device when the clips are changing over, etc.
