Output format – Note regarding simultaneous output to the SDI OUT terminal and the HDMI terminal [X2]
242
Note regarding simultaneous output to the SDI OUT terminal and the
HDMI terminal [X2]
It is possible to output from both the <SDI OUT> terminal and the <HDMI> terminal to the external device at the
same time.
The formats that can be output differ depending on the following setting combinations.
•
[SYSTEM] menu ¨ [FREQUENCY]
• [SYSTEM] menu ¨ [FILE FORMAT]
• [SYSTEM] menu ¨ [REC FORMAT]
• [VIDEO OUT/LCD/VF] menu ¨ [VIDEO OUT SEL] ¨ [SDI OUT FORMAT]
• [VIDEO OUT/LCD/VF] menu ¨ [VIDEO OUT SEL] ¨ [HDMI OUT FORMAT]
Make the following menu setting:
•
[VIDEO OUT/LCD/VF] menu ¨ [VIDEO OUT SEL] ¨ [SDI + HDMI OUTPUT] ¨ [ON]
When the [FREQUENCY] is set to [59.94Hz]
When the [FREQUENCY] is set to [50.00Hz]
* Factory setting
[REC FORMAT] <HDMI> terminal <SDI OUT> terminal
Resolution/frame rate [HDMI OUT FORMAT]: output format [SDI OUT FORMAT]: output format
3840×2160/59.94p [3840×2160p]: 3840×2160/59.94p 4:2:2 10 bit
[3840×2160p(420/8bit)]: 3840×2160/59.94p 4:2:0 8 bit
[1920×1080p]
*
: 1920×1080/59.94p 4:2:2 10 bit
[1920×1080p]
*
: 1920×1080/59.94p 4:2:2 10 bit
[1920×1080i]: 1920×1080/59.94i 4:2:2 10 bit [1920×1080i]: 1920×1080/59.94i 4:2:2 10 bit
3840×2160/29.97p [3840×2160p]: 3840×2160/29.97p 4:2:2 10 bit
[1920×1080p]
*
: 1920×1080/29.97p 4:2:2 10 bit
[1920×1080p]: 1920×1080/29.97p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/29.97PsF 4:2:2 10 bit
3840×2160/23.98p [3840×2160p]: 3840×2160/23.98p 4:2:2 10 bit
[1920×1080p]
*
: 1920×1080/23.98p 4:2:2 10 bit
[1920×1080p]: 1920×1080/23.98p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/23.98PsF 4:2:2 10 bit
1920×1080/59.94p [1920×1080p]
*
: 1920×1080/59.94p 4:2:2 10 bit [1920×1080p]
*
: 1920×1080/59.94p 4:2:2 10 bit
[1920×1080i]: 1920×1080/59.94i 4:2:2 10 bit [1920×1080i]: 1920×1080/59.94i 4:2:2 10 bit
1920×1080/59.94i [1920×1080i]: 1920×1080/59.94i 4:2:2 10 bit [1920×1080i]: 1920×1080/59.94i 4:2:2 10 bit
1920×1080/29.97p [1920×1080p]: 1920×1080/29.97p 4:2:2 10 bit [1920×1080p]: 1920×1080/29.97p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/29.97PsF 4:2:2 10 bit
1920×1080/23.98p [1920×1080p]: 1920×1080/23.98p 4:2:2 10 bit [1920×1080p]: 1920×1080/23.98p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/23.98PsF 4:2:2 10 bit
1280×720/59.94p [1280×720p]: 1280×720/59.94p 4:2:2 10 bit [1280×720p]: 1280×720/59.94p 4:2:2 10 bit
[REC FORMAT] <HDMI> terminal <SDI OUT> terminal
Resolution/frame rate [HDMI OUT FORMAT]: output format [SDI OUT FORMAT]: output format
3840×2160/50.00p [3840×2160p]: 3840×2160/50.00p 4:2:2 10 bit
[3840×2160p(420/8bit)]: 3840×2160/50.00p 4:2:0 8 bit
[1920×1080p]
*
: 1920×1080/50.00p 4:2:2 10 bit
[1920×1080p]
*
: 1920×1080/50.00p 4:2:2 10 bit
[1920×1080i]: 1920×1080/50.00i 4:2:2 10 bit [1920×1080i]: 1920×1080/50.00i 4:2:2 10 bit
3840×2160/25.00p [3840×2160p]: 3840×2160/25.00p 4:2:2 10 bit
[1920×1080p]
*
: 1920×1080/25.00p 4:2:2 10 bit
[1920×1080p]: 1920×1080/25.00p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/25.00PsF 4:2:2 10 bit
1920×1080/50.00p [1920×1080p]
*
: 1920×1080/50.00p 4:2:2 10 bit [1920×1080p]
*
: 1920×1080/50.00p 4:2:2 10 bit
[1920×1080i]: 1920×1080/50.00i 4:2:2 10 bit [1920×1080i]: 1920×1080/50.00i 4:2:2 10 bit
1920×1080/50.00i [1920×1080i]: 1920×1080/50.00i 4:2:2 10 bit [1920×1080i]: 1920×1080/50.00i 4:2:2 10 bit
1920×1080/25.00p [1920×1080p]: 1920×1080/25.00p 4:2:2 10 bit [1920×1080p]: 1920×1080/25.00p 4:2:2 10 bit
[1920×1080PsF]
*
: 1920×1080/25.00PsF 4:2:2 10 bit
1280×720/50.00p [1280×720p]: 1280×720/50.00p 4:2:2 10 bit [1280×720p]: 1280×720/50.00p 4:2:2 10 bit
