Panasonic BB-HCM511A

92
BB-HCM511A/BB-HCM531A
14.3.3.2. BB-HCM531A
C124 F1J0J1060006 10
C125 ECUE1H101JCQ 100p
C126 ECUE1H101JCQ 100p
C128 ECUE1C104ZFQ 0.1
C129 ECUE1C104ZFQ 0.1
C131 ECUE1H100DCQ 10p
C132 ECUE1H101JCQ 100p
C134 ECUE1C104ZFQ 0.1
C135 ECUE1C104ZFQ 0.1
C136 ECUE1C104ZFQ 0.1
C138 ECUE1H101JCQ 100p
C139 ECUE1H101JCQ 100p
C140 ECUE1H101JCQ 100p
C141 ECUE1C104ZFQ 0.1
C142 ECUE1C104ZFQ 0.1
C143 ECUE1C104ZFQ 0.1
C144 ECUE1H101JCQ 100p
C145 F1J0J1060006 10
C146 F1J0J1060006 10
C147 ECUE1C104ZFQ 0.1
C148 F1J0J1060006 10
C149 ECUE1H101JCQ 100p
C150 ECUE1H101JCQ 100p
C151 ECUE1H101JCQ 100p
C152 ECUE1H101JCQ 100p
C153 ECUE1H101JCQ 100p
C155 ECUE1H101JCQ 100p
C156 ECUE1H101JCQ 100p
C157 F1J0J1060006 10
C160 ECUE1C104ZFQ 0.1
C161 ECUE1C104ZFQ 0.1
C162 ECUE1C104ZFQ 0.1
C163 ECUE1H101JCQ 100p
C164 ECUE1C104ZFQ 0.1
C165 F1J0J1060006 10
C166 ECUE1C104ZFQ 0.1
C167 ECUE1C104ZFQ 0.1
C168 ECUE1H101JCQ 100p
C169 ECUE1H101JCQ 100p
C170 F1J0J1060006 10
C172 ECUE1H120JCQ 12p
C174 ECUE1H120JCQ 12p
C175 ECUE1H101JCQ 100p
C176 ECUE1C104ZFQ 0.1
C178 ECUE1C104ZFQ 0.1
C179 ECUE1C104ZFQ 0.1
C180 ECUE1H101JCQ 100p
C181 ECUE1C104ZFQ 0.1
C182 ECUV1A105ZFV 1
C187 ECUE1H102KBQ 0.001
C188 ECUE1H102KBQ 0.001
C189 ECUE1H102KBQ 0.001
C190 ECUE1C104ZFQ 0.1
C191 ECUE1C104ZFQ 0.1
C192 ECUE1C104ZFQ 0.1
C193 F1K1E106A059 10
C194 ECUE1C104ZFQ 0.1
C195 ECUE1H101JCQ 100p
C196 ECUE1C104ZFQ 0.1
C197 ECUE1H101JCQ 100p
C198 ECUE1H101JCQ 100p
C199 ECUE1H101JCQ 100p
C200 ECUE1C104ZFQ 0.1
C201 ECUE1C104ZFQ 0.1
C202 ECUE1C104ZFQ 0.1
C203 ECUE1C104ZFQ 0.1
C204 ECUE1C104ZFQ 0.1
C205 ECUE1H101JCQ 100p
C206 ECUE1C104ZFQ 0.1
C207 ECUE1C104ZFQ 0.1
C208 ECUE1C104ZFQ 0.1
C209 F1J0J1060006 10
C210 ECST0JX476 47 S
Safe
ty
Ref.
No.
Part No. Part Name & Description Rema
rks
C211 ECST0JX336 33 S
C212 F1J0J1060006 10
C213 ECUE1C104ZFQ 0.1
C215 ECUE1C104ZFQ 0.1
C217 F1J0J1060006 10
C218 ECUE1C104ZFQ 0.1
C219 F1J0J1060006 10
C220 ECUV0J105KBV 1 S
C221 ECUE1H6R0CCQ 6
C222 ECUE1C104ZFQ 0.1
C225 F1K1E106A059 10
C227 ECUE1C104ZFQ 0.1
C230 ECUE1A104KBQ 0.1
C232 ECUV0J105KBV 1 S
C233 ECUV1C104ZFV 0.1
C234 PFCX1EY106ZF 10 S
C235 ECUE1A104KBQ 0.1
C237 ECUV1C104ZFV 0.1
C238 ECUE1A104KBQ 0.1
C239 ECUE1A104KBQ 0.1
C240 PFCX1EY106ZF 10 S
C241 ECUE1A104KBQ 0.1
C244 ECUE1A104KBQ 0.1
C245 ECUE1A104KBQ 0.1
C246 ECJ1VB1E103K 0.01 S
C248 ECUV1A105ZFV 1
C249 F3F0J4760005 47
C252 ECUV1C104ZFV 0.1
C253 ECUV1C104ZFV 0.1
C255 F1J0J1060006 10
C256 F1J0J1060006 10
C258 ECUE0J105KBQ 1
C259 ECUE1C104ZFQ 0.1
C260 ECUE1C104ZFQ 0.1
C261 F1J0J1060006 10
C262 ECUE1C104ZFQ 0.1
C263 F1J0J1060006 10
C267 ECUE1C104ZFQ 0.1
C270 ECUE1H101JCQ 100p
(OTHER)
E1 PQHR11295Z S P ACER
Safe
ty
Ref.
No.
Part No. Part Name & Description Rema
rks
PCB1 PQWP1HCM531A CPU BOARD ASS'Y (RTL)
(ICs)
IC101 C0EBE0000231 IC
IC102 MN103SC30EYD IC
IC103 C3ABQG000079 IC
IC104 There is no parts supply of only IC104 please
order PCB1 (PQWP1HCM531A).
IC105 C1CB00002569 IC
IC106 C3ABQG000079 IC
IC107 C0BBBA000044 IC
IC108 C0GBF0000020 IC
IC109 C1AB00002139 IC
IC110 C1ZBZ0003497 IC
IC114 C0DBAFZ00054 IC
IC116 RPI-352 IC S
IC117 C0DBGYY00198 IC
(TRANSISTORS)
Q101 2SA1576R TRANSISTOR(SI) S
Q102 PQVTDTC143E TRANSISTOR(SI) S
Q103 PQVTDTC143E TRANSISTOR(SI) S
Q106 PQVTDTC143E TRANSISTOR(SI) S
Q107 PQVTDTC143E TRANSISTOR(SI) S
IC111 B1DHCD000018 TRANSISTOR(SI)
Safe
ty
Ref.
No.
Part No. Part Name & Description Rema
rks
