Panasonic BB-HCM511A

93
BB-HCM511A/BB-HCM531A
(DIODES)
D101 MA741WK D I O D E(SI ) S
D102 M A 7 36 D I ODE(S I ) S
D103 M A 3 082 DIOD E ( SI) S
LED101 B3ABB0000291 D I O D E(SI )
(CONNECTORS)
CN102 K1MN27BA0184 CONNECTOR# 27 Pin
CN103 K1MY04AA0057 CONNECTOR# 4 Pin
CN104 K1MN18BA0160 CONNECTOR# 18 Pin
CN105 K1NA14E00002 CONNECTOR# 14 Pin
CN106 K1MN32BA0153 CONNECTOR# 32 Pin
(COILS AND CERAMIC FIL-
TERS)
L101 G1C1R0JA0041 COIL
L102 G1C1R0JA0041 COIL
L103 G1C1R0JA0041 COIL
L108 G1C4R7MA0098 COIL
L112 J0JBC0000071 C E R A M I C F I L T E R
L114 J0JBC0000071 C E R A M I C F I L T E R
L115 J0JBC0000071 C E R A M I C F I L T E R
L116 G1C1R0JA0041 COIL
L118 J0JBC0000071 C E R A M I C F I L T E R
L119 G1C1R0JA0041 COIL
L120 J0JBC0000071 C E R A M I C F I L T E R
L121 G1A220GA0005 COIL
L124 G1C100M00027 COIL
L126 PQLQR1RS241 COIL S
L127 G1C100M00027 COIL
R141 J0JCC0000315 C E R A M I C F I L T E R
R146 PQLQR1RM601 COIL S
R147 PQLQR1RM601 COIL S
R148 PQLQR1RM601 COIL S
R149 PQLQR1RM601 COIL S
R152 J0JCC0000315 C E R A M I C F I L T E R
R153 J0JCC0000315 C E R A M I C F I L T E R
R154 J0JCC0000315 C E R A M I C F I L T E R
R155 J0JCC0000315 C E R A M I C F I L T E R
R156 J0JCC0000315 C E R A M I C F I L T E R
R157 J0JCC0000315 C E R A M I C F I L T E R
R158 J0JCC0000315 C E R A M I C F I L T E R
R159 J0JCC0000315 C E R A M I C F I L T E R
R160 J0JCC0000315 C E R A M I C F I L T E R
R161 J0JCC0000315 C E R A M I C F I L T E R
R162 J0JCC0000315 C E R A M I C F I L T E R
R163 J0JCC0000315 C E R A M I C F I L T E R
R164 J0JCC0000315 C E R A M I C F I L T E R
R187 J0JCC0000315 C E R A M I C F I L T E R
R188 J0JCC0000315 C E R A M I C F I L T E R
R190 J0JCC0000315 C E R A M I C F I L T E R
R191 J0JCC0000315 C E R A M I C F I L T E R
R192 J0JCC0000315 C E R A M I C F I L T E R
R193 J0JCC0000315 C E R A M I C F I L T E R
R194 J0JCC0000315 C E R A M I C F I L T E R
R226 J0JCC0000250 C E R A M I C F I L T E R
R228 J0JCC0000315 C E R A M I C F I L T E R
R229 J0JCC0000315 C E R A M I C F I L T E R
R230 J0JCC0000315 C E R A M I C F I L T E R
R231 J0JCC0000315 C E R A M I C F I L T E R
R232 J0JCC0000315 C E R A M I C F I L T E R
R233 PQLQR1RM601 COIL S
R234 PQLQR1RM601 COIL S
R235 PQLQR1RM601 COIL S
R236 PQLQR1RM601 COIL S
R237 PQLQR1RM601 COIL S
R238 PQLQR1RM601 COIL S
R244 J0JCC0000250 C E R A M I C F I L T E R
R245 J0JCC0000250 C E R A M I C F I L T E R
R261 J0JCC0000315 C E R A M I C F I L T E R
R269 J0JCC0000250 C E R A M I C F I L T E R
Safe
ty
Ref.
No.
Part No. Part Name & Description Rema
rks
(COMPONENTS PARTS)
RA101 D1H84724A024 RESISTOR ARRAY
RA105 D1H84704A024 RESISTOR ARRAY
RA107 D1H84704A024 RESISTOR ARRAY
RA110 D1H84704A024 RESISTOR ARRAY
(IC FILTERS)
L128 J0JBC0000107 IC FILTER
RA102 J0JAD0000007 IC FILTER
RA103 J0JAD0000007 IC FILTER
RA104 J0JAD0000007 IC FILTER
(SWITCHES)
SW101 EVQPSM02K PUSH SWITCH
SW102 EVQPSM02K PUSH SWITCH
SW103 EVQPSM02K PUSH SWITCH
(CRYSTAL OSCILLATORS)
X101 H0J480500030 CRYSTAL OSCILLATOR
X102 H0J250500084 CRYSTAL OSCILLATOR
X103 H0J327200193 CRYSTAL OSCILLATOR
(RESISTORS)
R101 ERJ2GEJ103 10k
R102 ERJ2GEJ103 10k
R103 ERJ2GEJ102 1k
R104 ERJ2GEJ102 1k
R105 ERJ2GE0R00 0
R106 ERJ2GE0R00 0
R107 ERJ2GEJ103 10k
R108 ERJ2GEJ561 560
R109 ERJ2GEJ105X 1M
R111 ERJ2RKF1501X 1.5k
R112 ERJ2RKF1002 10k
R113 ERJ2GEJ272 2.7k
R114 ERJ2RKF6801 6.8k
R115 ERJ2RKF4871 4.87k
R116 ERJ2RKF3302 30k
R118 ERJ2RKF1210 121
R119 ERJ2GE0R00 0
R120 ERJ2GEJ151 150
R121 ERJ3GEYJ103 10k
R122 ERJ2GEJ103 10k
R123 ERJ2GEJ101 100
R124 ERJ2GE0R00 0
R125 ERJ2GEJ470 47
R126 ERJ2GEJ103 10k
R127 ERJ2GEJ470 47
R128 ERJ2GEJ470 47
R129 ERJ2GEJ472X 4.7k
R130 ERJ2GEJ470 47
R131 ERJ2GEJ470 47
R132 ERJ2GEJ470 47
R133 ERJ2GEJ105X 1M
R134 ERJ2GE0R00 0
R135 ERJ2GEJ103 10k
R136 ERJ2RKF6801 6.8k
R137 ERJ3EKF49R9 49.9
R138 ERJ3EKF49R9 49.9
R139 ERJ3EKF49R9 49.9
R140 ERJ3EKF49R9 49.9
R142 ERJ2GE0R00 0
R143 ERJ2GEJ470 47
R144 ERJ2GEJ470 47
R145 ERJ2GEJ470 47
R150 ERJ2GEJ103 10k
R151 ERJ2GEJ103 10k
R165 ERJ2GEJ103 10k
R166 ERJ2GEJ103 10k
R167 ERJ2GEJ103 10k
R168 ERJ2GEJ104 100k
R170 ERJ2GEJ472X 4.7k
R171 ERJ2GEJ104 100k
Safe
ty
Ref.
No.
Part No. Part Name & Description Rema
rks
