Panasonic DMR-ES30V

16
S
RF IN
RF OUT
AC IN~
OPTICAL
VIDEO
AUDIO
S VIDEO
L
R
P
B
P
R
Y
DVD OU T
Connecting with S VIDEO cable
1
Aerial
RF IN
Aerial input
RF OUT
Aerial output
S VIDEO-output
AUDIO/VIDEO output
4
TV
Aerial input
Audio cable (L/R)
S VIDEO cable
3
S VIDEO input
Audio/Video input
RF Coaxial cable
2
AC mains lead
S
S
AC IN~
44
AC mains lead
VIDEO
AUDIO
S VIDEO
L
R
Red (R)
White (L)
3
15
(DVD only)
DVD Recorder
Aerial
infeed line
With an S VIDEO cable and an
Audio cable
Connecting the TV Setup
Automatic setup
Follow the steps below.
Disconnect the power to all units.
1 Connect the aerial to the RF IN (aerial input) of the
DVD Recorder.
2 Connect the RF OUT (aerial output) of the DVD Recorder
to the aerial input of the television set.
3 Connect the DVD OUT (AUDIO L/R, S VIDEO) of the DVD
Recorder to the input of the television set.
4 Plug the DVD Recorder and the television set into the
AC mains socket.
= Extra equipment for the connection shown: S VIDEO cable,
Aerial infeed line
