Panasonic DMR-ES30V

RF IN
RF OUT
AC IN~
OPTICAL
VIDEO
AUDIO
S VIDEO
L
R
P
B
P
R
Y
CLASS 1
LASER PRODUCT
DVD OUT
9 10 8
76
1
2
3
4 5
Rear Panel
7
AC IN~ = Power supply
1
DVD OUT VHS/DVD COMMON
3
4
7
2
P
B
P
R
Y
5
6
8
9
10
RF IN = Antenna input
OPTICAL = Digital audio output
= Chrominance signal (colour difference)
= Chrominance signal (colour difference)
= Luminance signal (luminance)
COMPONENT VIDEO OUT
R-AUDIO-L = Audio output right/left channel
VIDEO = Video output
S VIDEO = S VIDEO out connector
RF OUT = Antenna output
AV1 (TV)
21-pin Scart socket = TV connection
AV2 (DECODER/EXT)
21-pin Scart socket = connection of an external unit
