Panasonic DMR-ES40VP User Manual

S-50
S5.1.3. Main P.C.B. Address Information
Address Information
C.....Component Side
F......Foil Side
Capacitor
C2001 H-8 F
C2003 K-10 F
C2051 I-16 C
C2053 J-15 C
C2054 G-8 F
C2055 G-8 F
C2099 J-12 F
C2501 L-9 F
C2502 L-13 C
C2504 L-10 F
C2505 L-10 F
C2506 L-10 F
C2507 L-10 F
C2508 K-10 F
C2509 L-13 C
C2510 K-11 F
C2511
K-10 F
C2512 K-11 F
C2513 K-10 F
C2515 L-10 F
C2518 K-10 F
C2519 L-10 F
C2551 K-9 F
C2552 K-10 F
C2561 K-10 F
C2562 F-8 F
C2571 K-10 C
C3001 G-12 F
C3002 H-12 F
C3003 H-12 F
C3004 J-9 C
C3005 G-12 F
C3006 G-12 F
C3007 I-12 F
C3008 I-10 C
C3009 I-12 F
C3010 J-12 F
C3011
H-12 F
C3012 I-10 C
C3013 J-9 C
C3014 H-11 F
C3015 H-11 F
C3016 J-13 F
C3017 H-11 F
C3019 H-11 F
C3020 I-11 C
C3021 H-10 C
C3022 H-11 F
C3023 H-10 F
C3024 G-11 F
C3025 G-10 F
C3026 I-11 C
C3028 F-11 C
C3029 F-11 C
C3030 F-11 F
C3031 F-11 F
C3032 F-11 C
C3033 F-10 F
C3034 E-11 C
C3035 E-11 F
C3036 F-12 C
C3037 F-10 F
C3038 G-10 F
C3039 F-12 C
C3040 G-10 F
C3041 G-10 F
C3043 J-13 F
C3044 F-10 F
C3048 I-12 F
C3050 H-11 F
C3051 J-13 F
C3052 K-9 C
C3053 H-10 F
C3074 H-11 F
C3701 L-6 C
C3702 L-16 F
C3703 L-15 F
C3704 L-7 C
C3705 L-15 F
C3706 L-15 F
C3707 L-7 C
C3708 K-15 F
C3709 K-7 C
C3710 L-15 F
C3711
K-15 F
C3712 K-16 F
C3713 B-15 C
C3713 K-17 F
C3715 K-17 F
C3716 K-17 F
C3717 K-17 F
C3718 K-17 F
C3719 B-15 C
C3719 K-17 F
C3720 K-16 F
C3721 K-16 F
C3722 K-16 F
C3723 K-17 F
C3724 K-17 F
C3725 K-16 F
C3726 M-6 C
C3727 M-5 C
C3728 M-5 C
C3729 M-16 F
C3730 M-5 C
C3731 M-16 F
C3732 L-5 C
C3733 M-5 C
C3734 L-5 C
C3735 L-5 C
C3736 L-17 F
C3737 L-17 F
C3738 L-17 F
C3908 G-17 F
C3918 D-18 F
C3919 E-18 F
C3925 I-16 F
C3926 I-15 F
C3927 I-16 F
C3928 I-6 C
C3932 H-17 F
C3933 E-4 C
C4001 B-16 C
C4004 G-13 F
C4005 G-10 C
C4006 G-9 C
C4007 G-13 F
C4008 G-9 C
C4009 G-9 C
C4011
G-12 F
C4012 F-10 C
C4013 F-12 F
C4017 G-10 C
C4019 G-9 C
C4081 C-6 F
C4082 C-5 F
C4083 B-16 C
C4084 C-6 F
C4085 C-6 F
C4085 C-6 F
C4101 J-18 F
C4102 F-18 F
C4103 J-18 F
C4104 F-18 F
C4105 G-18 F
C4107 G-18 F
C4109 F-18 F
C4111
F-18 F
C4501 E-9 C
C4502 E-9 C
C4503 E-10 C
C4504 E-9 C
C4505 F-10 C
C4506 F-9 C
C4507 F-10 C
C4508 E-12 F
C4509 E-12 F
C4510 E-12 F
C4511 E-11
F
C4512 E-11 F
C4513 D-11 C
C4514 D-11 C
C4515 D-12 C
C4516 D-11 C
C4517 D-11 C
C4518 E-11 F
C4519 C-5 F
C4520 C-17 C
C4521 D-9 C
C4522 D-11 C
C4523 D-9 C
C4524 D-13 F
C4525 D-9 C
C4526 D-9 C
C4534 F-10 C
C4535 E-11 C
C4535 D-11 C
C4537 D-11 F
C4538 D-13 F
C4773 D-13 F
C4774 D-13 F
C4801 J-18 F
C4802 J-18 F
C4803 H-7 C
C4804 H-7 C
C4805 H-6 C
C4806 G-6 C
C4807 G-6 C
C4808 H-16 F
C4809 H-6 C
C4810 H-6 C
C4811
E-5 C
C4812 F-6 C
C4813 F-6 C
C4814 F-14 F
C4815 K-13 F
C4816 F-5 C
C4817 F-6 C
C4817 F-5 C
C4818 E-6 C
C4819 E-5 C
C4820 E-6 C
C4821 F-16 F
C4822 D-17 F
C4823 E-16 F
C4824 F-16 F
C4826 F-16 F
C4827 E-5 C
C4828 F-16 F
C4829 G-5 C
C4830 G-5 C
C4831 K-18 F
C4832 K-4 C
C4833 D-5 C
C4834 F-15 F
C4835 D-17 F
C4836 E-6 C
C4837 F-7 C
C4838 E-5 C
C4839 E-6 C
C4840 F-6 C
C4841 D-17 F
C4842 F-7 C
C4843 E-6 C
C4844 E-6 C
C5001 F-12 F
C5002 F-12 F
C5003 F-12 F
C5004 F-12 F
C5005 F-11 F
C5006 F-10 C
C5007 F-11 F
C5008 E-11 F
C6001 F-6 F
C6002 F-6 F
C6005 I-16 C
C6006 F-7 F
C6007 F-7 F
C6008 F-7 F
C6009 E-7 F
C6010 F-8 F
C6011
F-8 F
C6012 H-7 F
C6014 F-7 F
C6015 E-7 F
C6016 F-7 F
C6018 F-6 F
C6019 F-6 F
C6020 E-5 F
C6101 F-7 F
C6102 E-8 F
C6103 E-7 F
C6104 E-6 F
C6201 F-6 F
C6301 D-6 F
C6302 D-6 F
C6303 D-16 C
C6308 K-13 C
C7031 B-16 C
C7302 C-7 F
C7303 B-7 F
C7304 C-7 F
C7305 C-7 F
C7306 B-14 C
C7307 B-14 C
C7308 B-14 C
C7309 B-7 F
C7310 B-7 F
C7311
B-7 F
C7312 C-8 F
C7314 B-15 C
C7315 B-14 C
C7316 B-8 F
C7316 B-8 F
C7317 B-8 F
C7318 B-14 C
C7320 B-7 F
C7321 B-11 C
C7322 B-11 C
C7401 C-6 C
C7403 C-17 F
C7404 C-4 C
C7405 B-17 F
C7406 B-17 F
C7407 C-17 F
C7408 C-17 F
C7419 B-16 F
C7420 B-16 F
C7421 C-5 C
C7422 B-17 F
C7423 B-16 F
C7432 C-17 F
C7433 B-18 F
C7434 C-17 F
C7435 D-15 F
C7436 D-15 F
C7437 K-15 F
C7438 J-14 F
C7501 K-5 F
C7502 K-5 F
C7503 K-5 F
C7503 K-5 F
C7504 F-18 C
C7505 H-4 F
C7506 H-4 F
C7507 I-5 F
C7508 I-5 F
C7509 I-5 F
C7510 J-5 F
C7511 J-5 F
C7512 J-5 F
C7513 J-5 F
C7515 J-6 F
C7516 L-6 F
C7517 H-5 F
C7518 J-5 F
C7538 F-18 C
C7539 M-15 C
C7540 K-6 F
CL3701 J-16 F
CL6011
F-7 F
CL6012 F-9 F
CL6021 F-8 F
CL6022 F-8 F
CL6023 F-8 F
CL6024 F-8 F
CL6025 F-7 F
CL6026 G-6 F
CL6027 G-7 F
CL6028 H-7 F
CL6029 G-7 F
CL6030 F-6 F
CL6031 F-7 F
CL7506 I-4 F
CL7507 M-4 F
Diode
D1501 H-14 C
D2001 H-14 C
D2002 I-14 C
D2502 L-11 C
D3001 J-9 C
D3002 J-9 C
D4501 E-11 C
D4502 C-17 C
D6001 E-18 C
D6306 D-16 C
D7401 C-6 C
D7501 K-16 C
D7502 I-17 C
D7751 E-18 C
DP7501 J-18 C
Fuse
F7502 L-5 F
Filter
FL7301 B-12 C
Integrated Circuit
IC1511
I-16 C
IC1512 E-16 C
IC2501 L-10 F
IC3001 G-11 F
IC3002 K-13 F
IC3701 K-16 F
IC3902 I-16 F
IC4501 D-12 F
IC4801 H-16 F
IC4802 H-16 F
IC4803 D-17 F
IC4804 F-16 F
IC6001 G-7 F
IC6201 F-6 F
IC6301 K-9 F
IC7301 B-7 F
IC7401 C-17 F
IC7402 C-17 F
IC7501 K-5 F
IC7502 L-6 F
IP6001 D-6 F
Earth Wire
J1 I-9 C
Connector
JK3902 I-4
C
JK3903 E-4 C
JK4801 K-4 C
Coil
L3002 G-10 C
L3003 I-11 C
L3004 G-12 C
L3005 F-12 C
L3006 F-10 F
L3701 M-7 C
L3702 J-7 C
L4061 B-16 C
L4501 D-12 C
L4502 E-11 C
L4503 C-8 C
L5001 E-11 C
L6001 F-6 F
L6101 E-15 C
L6102 F-15 C
L6801 K-4 C
L7301 B-15 C
L7401 J-8 C
L7402 C-5 C
LB3101 H-18 F
LB3102 I-18 F
LB3103 I-18 F
LB3104 I-18 F
LB3105 E-18 F
LB3106 H-18 F
LB3107 G-18 F
LB3108 E-18 F
LB3110
D-18 F
LB3111
D-18 F
LB4101 J-18 F
LB4102 F-18 F
LB4103 I-18 F
LB4104 F-18 F
LB4105 G-18 F
LB4107 F-18 F
LB7403 B-17 F
LB7405 C-17 F
LB7407 C-17 F
LB7408 B-18 F
LB7409 B-18 F
LB7410 B-18 F
LB7411
B-18 F
LB7412 B-17 F
LB7505 L-5 F
Test Point
MK1 F-7 F
MK10 K-5 F
MK2 G-7 F
MK3 G-11 F
MK4 G-11 F
MK5 D-12 F
MK57 M-8 F
MK58 I-9 F
MK59 G-10 F
MK6 D-12 F
MK60 B-9 F
MK62 H-13 F
MK64 G-15 F
MK7 L-16 F
MK8 K-16 F
MK9 K-5 F
TL1002 C-5 F
TL2015 H-8 F
TL23 I-6 F
TL24 E-6 F
TL2502 J-10 F
TL4501 C-11 F
TL4502 C-11 F
TL4507 E-11 F
TL6001 K-9 F
TL6002 M-7 F
TL6004 F-6 F
TL6010 G-6 F
TL7503 K-5 F
TL7504 L-5 F
Connector
P1531 M-10 C
P2501 K-10 C
P2571 K-11 C
P3001 F-10 C
P4001 C-12 C
P4002 J-10 C
P6001 M-7 C
P6002 M-8 C
P6003 M-10 C
P7501 H-18 C
P7502 M-18 C
PH7501 H-18 C
PS6002 C-18 C
Transistor
Q1501 M-13 C
Q1502 B-13 C
Q3001 E-10 F
Q3002 J-8 C
Q3003 J-8 C
Q3004 H-10 F
Q3901 I-16 F
Q3902 I-16 F
Q4001 H-13 F
Q4002 G-13 F
Q4081 C-16 C
Q4084 C-6 F
Q4501 C-14 F
Q4502 C-17 C
Q4801 F-17 F
Q4801 G-18 F
Q4802 F-18 F
Q6305 D-6 F
Q7401 C-15 F
Q7402 C-17 F
Q7501 M-5 F
Transistor-resistor
QR4001 G-13 F
QR4082 C-6 F
QR4501 C-15 F
QR4802 I-17 F
QR4803 F-18 F
QR4804 J-18 F
QR4805 J-18 F
QR4806 J-18 F
QR4807 F-18 F
QR4810 G-15 F
QR4811
G-16 F
QR4812 G-17 F
QR4813 G-17 F
QR4816 J-17 F
QR6801 J-7 F
QR7401 C-17 F
QR7501 L-5 F
QR7503 L-5 F
Resistor
R1501 H-7 F
R1502 C-8 F
R1503 H-14 C
R1511
E-6 F
R1512 I-7 F
R1513 I-7 F
R2001 K-10 F
R2002 H-8 F
R2099 I-12 F
R2501 K-10 F
R2502 K-10 F
R2503 K-12 C
R2514 K-10 F
R2515 K-10 F
R2516 K-11 F
R2520 K-10 F
R2521 K-10 F
R2551 F-8 F
R2552 K-9 F
R2561 F-8 F
R2562 J-10 F
R2563 G-8 F
R2564 K-10 F
R2565 K-10 F
R3001 G-12 F
R3002 G-12 F
R3003 J-8 C
R3006 K-10 C
R3009 F-11 F
R3011 F-11
F
R3012 F-11 F
R3013 F-11 F
R3014 F-11 F
R3016 G-10 F
R3017 E-10 F
R3021 H-12 F
R3022 H-12 F
R3023 I-10 F
R3030 H-10 F
R3031 I-10 F
R3032 G-12 F
R3035 F-11 F
R3046 E-10 F
R3047 E-10 F
R3701 L-15 F
R3702 L-16 F
R3703 K-15 F
R3704 K-15 F
R3707 K-15 F
R3708 K-16 F
R3710 K-17 F
R3711
K-17 F
R3907 H-18 F
R3908 I-18 F
R3909 I-18 F
R3912 I-18 F
R3913 E-18 F
R3914 G-18 F
R3915 G-17 F
R3922 G-17 F
R3924 E-18 F
R3926 D-18 F
R3928 D-18 F
R3929 D-17 F
R3932 I-16 F
R3933 I-16 F
R3934 I-16 F
R3935 I-16 F
R3936 I-16 F
R3937 I-16 F
R3938 I-16 F
R3939 H-17 F
R3940 H-17 F
R4001 H-13 F
R4003 F-13 F
R4004 G-12 F
R4005 G-13 F
R4006 G-13 F
R4007 G-12 F
R4008 G-12 F
R4009 C-6 F
R4011
F-13 F
R4012 G-13 F
R4081 C-6 F
R4081 C-6 F
R4086 C-6 F
R4087 C-6 F
R4500 E-11 F
R4501 D-13 F
R4502 E-12 F
R4503 E-12 F
R4504 C-17 C
R4505 E-12 F
R4506 E-12 F
R4507 C-14 F
R4508 D-10 F
R4509 F-13 F
R4510 F-13 F
R4511
F-13 F
R4512 F-12 F
R4513 C-15 F
R4515 D-13 F
R4518 E-13 F
R4519 E-13 F
R4520 F-12 F
R4521 E-12 F
R4522 D-11 F
R4525 D-11 F
R4526 D-13 F
R4527 D-13 F
R4529 E-11 F
R4534 E-11 F
R4538 D-11 F
R4539 C-11 F
R4540 C-11 F
R4553 E-12 F
R4557 E-13 F
R4802 I-17 F
R4803 I-17 F
R4804 J-18 F
R4805 F-18 F
R4806 G-17 F
R4807 F-17 F
R4808 H-16 F
R4809 H-16 F
R4810 H-16 F
R4811
G-16 F
R4812 G-15 F
R4813 G-16 F
R4814 G-15 F
R4815 G-16 F
R4816 G-17 F
R4817 F-16 F
R4818 F-16 F
R4819 E-17 F
R4820 E-16 F
R4821 E-17 F
R4822 G-17 F
R4823 F-18 F
R4824 E-17 F
R4825 F-17 F
R4826 F-16 F
R4827 F-16 F
R4829 F-16 F
R4830 F-16 F
R4832 E-15 F
R4833 E-15 F
R4834 F-16 F
R4835 F-15 F
R4836 E-15 F
R4837 E-16 F
R4840 F-18 F
R4855 G-16 F
R4856 G-16 F
R4858 J-18 F
R4859 G-18 F
R4860 I-18 F
R4861 F-18 F
R4862 F-18 F
R4863 F-18 F
R6001 F-7 F
R6002 F-6 F
R6004 G-6 F
R6006 I-6 F
R6007 H-7 F
R6008 G-6 F
R6009 E-8 F
R6010 E-8 F
R6011
H-7 F
R6012 F-8 F
R6013 F-8 F
R6014 H-7 F
R6015 D-5 F
R6017 F-7 F
R6018 E-7 F
R6019 H-7 F
R6020 G-7 F
R6022 F-8 F
R6023 F-8 F
R6024 G-7 F
R6026 F-8 F
R6027 F-8 F
R6028 F-8 F
R6029 F-8 F
R6101 E-7 F
R6102 E-7 F
R6103 E-7 F
R6201 F-6 F
R6309 D-6 F
R6801 I-7 F
R6802 I-7 F
R6803 H-8 F
R7301 B-7 F
R7303 B-7 F
R7305 B-8 F
R7306 B-8 F
R7307 B-7 F
R7309 B-8 F
R7310 B-10 F
R7311
B-9 F
R7401 C-6 C
R7403 C-17 F
R7404 C-17 F
R7405 C-17 F
R7406 C-17 F
R7407 D-17 F
R7408 D-17 F
R7409 D-17 F
R7410 B-16 F
R7411
B-16 F
R7415 C-16 F
R7416 D-17 F
R7417 C-15 F
R7418 C-15 F
R7501 K-5 F
R7503 L-5 F
R7504 I-4 F
R7505 I-5 F
R7506 I-5 F
R7507 M-17 C
R7508 I-18 C
R7509 G-4 F
R7510 J-5 F
R7511
I-5 F
R7512 I-5 F
R7513 J-5 F
R7514 J-5 F
R7514 J-5 F
R7515 J-5 F
R7516 J-5 F
R7517 J-5 F
R7518 K-4 F
R7519 K-5 F
R7520 L-5 F
R7520 K-5 F
R7521 G-4 F
R7522 G-4 F
R7524 J-4 F
R7527 L-5 F
R7528 K-5 F
R7529 K-5 F
R7530 J-5 F
R7537 K-5 F
R7538 K-4 F
R7539 K-4 F
R7540 K-4 F
R7541 K-4 F
R7542 K-4 F
R7543 L-5 F
R7554 L-5 F
R7556 K-6 F
R7561 J-6 F
R7562 J-4 F
R7563 J-4 F
R7564 J-4 F
R7565 J-4 F
Switch
S1531 D-17 C
S1532 K-15 C
Tuner Unit
TU7401 B-5 C
Crystal Osillator
X3002 F-11 C
X6001 F-16
C
X7501 J-17
C
X7502 J-17
C
Main

P.C.B

Panasonic DMR-ES40VP Specifications

General

Brand	Panasonic
Model	DMR-ES40VP
Category	DVD Recorder
Language	English
