Panasonic DMR-ES40VP

DMR-ES40VP-S
06 / 07 / M1 / M2
Ref.No. Part No. Part Name & Description
P
c
s
Remarks Ref.No. Part No. Part Name & Description
P
c
s
Remarks
30 VKC0295 PCB HOLDER 1
R3801 ERJ3GEYJ750V 1/10W 75 1 31 VKC0295 PCB HOLDER 1
R3802 ERJ3GEYJ750V 1/10W 75 1 32 VMX3115 MECHA SPACER(F) 1
R3803 ERJ3GEYJ750V 1/10W 75 1 33 VMX3229 MECHA SPACER(R) 1
R3804 ERJ3GEYJ102V 1/10W 1K 1 34 VMX3277 SPACER 1
R7801 D0GB221JA041 1/10W 220 1 35 XTV26+5FFJ SCREW 1
R7802 D0GB182JA007 1/10W 1.8K 1 36 XTW3+10PN SCREW 1
R7807 D0GB182JA007 1/10W 1.8K 1 37 XSN3+4FJK SCREW 1
 39 VGM2077 TOP PANEL 1
S7805 EVQ11G07K SWITCH,FF 1 40 RFKNVXY1867 RAM DRIVE UNIT 1 (RTL)(SPG)
S7806 EVQ11G07K SWITCH,POWER 1 40-1 RMV0307 BARRIER 1 (SPG)
S7812 EVQ11G07K SWITCH,REW 1 41 RHD30111-3 SCREW 1
S7813 EVQ11G07K SWITCH,EJECT 1 42 RHD30111-3 SCREW 1
43 RHD30111-3 SCREW 1
44 RHD30111-3 SCREW 1
■ 07 VEP07A85A 1 (FL DRIVE P.C.B.) 45 RHD30111-3 SCREW 1
46 RHD30111-3 SCREW 1
47 RHD30111-3 SCREW 1
D27501 B3AAA0000752 DIODE 1 48 RHD30111-3 SCREW 1
D27503 B3ACA0000273 DIODE 1 49 RHD30111-3 SCREW 1
D27505 B3ADA0000173 DIODE 1 50 RHD30111-3 SCREW 1
51 RHD30111-3 SCREW 1
PP27501 K1KA08B00210 CONNECTOR(8P) 1 52 RHD30111-3 SCREW 1
53 RHD30111-3 SCREW 1
QR27501 UNR521100L TRANSISTOR 1 54 RHD30111-3 SCREW 1
QR27503 UNR521100L TRANSISTOR 1 55 RHD30111-3 SCREW 1
QR27505 UNR521100L TRANSISTOR 1 56 RHD30111-3 SCREW 1
58 RHD30115-3 SCREW 1
R27501 D0GB221JA041 1/10W 220 1 59 RHD30115-3 SCREW 1
R27503 D0GB331JA007 1/10W 330 1 60 RHD30115-3 SCREW 1
R27505 D0GB331JA007 1/10W 330 1 61 VHD1453-2 SCREW 1
R27508 ERJ3GEYJ122V 1/10W 1.2K 1 62 VHD1453-2 SCREW 1
R27509 ERJ3GEYJ122V 1/10W 1.2K 1 63 VHD1453-2 SCREW 1
R27511 D0GB152JA007 1/10W 1.5K 1 67 VHD0690-1 SCREW 1
R27516 D0GB152JA007 1/10W 1.5K 1 68 VHD0690-1 SCREW 1
R27517 D0GB222JA041 1/10W 2.2K 1 69 VHD0690-1 SCREW 1
R27532 D0GB222JA041 1/10W 2.2K 1 70 VHD0690-1 SCREW 1
71 VHD0690-1 SCREW 1
S27501 EVQ11G04M SWITCH,OPEN/CLOSE 1 72 VHD0690-1 SCREW 1
S27502 EVQ11G07K SWITCH,CH DOWN 1 73 VHD0690-1 SCREW 1
S27503 EVQ11G07K SWITCH,STOP 1 74 VHD0690-1 SCREW 1
S27504 EVQ11G07K SWITCH,CH UP 1 75 VHD0690-1 SCREW 1
S27505 EVQ11G07K SWITCH,PLAY 1 76 VHD0690-1 SCREW 1
S27506 EVQ11G07K SWITCH,REC 1 77 RHD30113 SCREW 1
S27507 EVQ11G07K SWITCH,D2V 1 78 RHD30113 SCREW 1
S27508 EVQ11G07K SWITCH,V2D 1 79 RHD30113 SCREW 1
S27509 EVQ11G07K SWITCH,SELECT 1 80 RHD30113 SCREW 1
■ M2 M2_GAISO 1
■ M1 M1_GAISO 1
6 VEP04888A FRONT JACK P.C.B. 1 (RTL)
1 VEE1B46 WIRE WITH CONNECTOR(5P) 1 7 VEP07A85A FL DRIVE P.C.B. 1 (RTL)
2 VEE1B87 WIRE WITH CONNECTOR(4P) 1 27 RYP1286-S FRONT PANEL ASS'Y 1 (P)
3 VWJ1796 FFC(40P) 1 27 RYP1286A-S FRONT PANEL ASS'Y 1 (PC)
4 VEP06F99A MAIN P.C.B. 1 (RTL) 27-1 RGU2375-S DUB BUTTON (2) 1
5 VEP001K8A DV JACK P.C.B. 1 (RTL) 27-3 RKW0791-Q FRONT WINDOW 1
8 VEP09138A DIGITAL I/F P.C.B. 1 (RTL) 27-4 RKW0781-Q DUB WINDOW 1
9 VEP79115B DIGITAL P.C.B. 1 (RTL)(P) 27-5 RGL0673-W PANEL LIGHT 1
9 RFKBES40VPC DIGITAL P.C.B. 1 (RTL)(PC) 27-6 RGU2369-W POWER BUTTON 1
10 VWJ1727 FFC(7P) 1 27-7 RGU2370-S EJECT BUTTON 1
11 VWJ1728 FFC(6P) 1 27-8 RGU2371-S OPEN BUTTON 1
12 VJF0442 CLAMPER 1 27-10 RGU2411-S SELECT BUTTON 1
13 L6FALCCE0012 SMALL DC FAN MOTOR 1 27-11 RKF0722-S BLINDER PANEL 1
 14 RGR0360A-A REAR PANEL 1 (P) 27-12 RKF0723-S TRAY DOOR 1
 14 RGR0360A-B REAR PANEL 1 (PC) 27-14 RGU2374-H DUB BUTTON (1) 1
17 RMA1897 CENTER ANGLE 1 27-15 RYF0762D-S DOOR ASS'Y 1
18 RMA1947 DVD ANGEL 1 27-16 VMB2521 BLINDER SPRING 1
19 RMA1948 FRONT ANGEL 1 27-17 VMB3410 TRAY SPRING 1
21 RMZ0791 BARRIER 1 27-18 RYF0763B-S SD SLOT ASS'Y 1
22 RKA0178-X LEG 1 27-19 RHD26045-L SCREW 1
23 RKA0178-X LEG 1 27-20 RHD26045-L SCREW 1
24 VKA0382 LEG CUSHION 1 27-21 RHD26045-L SCREW 1
25 VKA0382 LEG CUSHION 1 27-22 RHD26045-L SCREW 1
28 VHD1452-2 SCREW 1 27-23 RHD26045-L SCREW 1
S‑67
