S-3
REF No. PIN No. REC PB EE
IC6001 45 0 0 0
IC6001 46 0 0 0
IC6001 47 1.4 1.4 1.4
IC6001 48 2.2 2.2 2.2
IC6001 49 0 0 0
IC6001 50 1 1 1
IC6001 51 5.1 5.1 5.1
IC6001 52 0 1.5 1.5
IC6001 53 5.1 5.1 5.1
IC6001 54 2 2.1 2
IC6001 55 1.4 1.4 1.5
IC6001 56 1.3 1.3 1.3
IC6001 57 0 0 0
IC6001 58 4.8 4.8 4.8
IC6001 59 0 0 0
IC6001 60 0 0 0
IC6001 61 0 0 0
IC6001 62 0 0 0
IC6001 63 0 0 0
IC6001 64 0 0 0
IC6001 65 0 0 0
IC6001 66 0 0 0
IC6001 67 0 0 0
IC6001 68 4.1 4.1 4.1
IC6001 69 3.9 3.9 3.9
IC6001 70 4.3 4.3 4.3
IC6001 71 4.2 4.2 4.2
IC6001 72 4.1 4.1 4.1
IC6001 73 0.1 0.1 0.1
IC6001 74 0 0 0
IC6001 75 4.6 4.6 4.6
IC6001 76 0 0 0
IC6001 77 4.8 4.8 4.8
IC6001 78 0 0 0
IC6001 79 5 5 5
IC6001 80 0.1 0.1 0.1
IC6001 81 0 0 0
IC6001 82 0 0 0
IC6001 83 0 0 0
IC6001 84 0 0 0
IC6001 85 0 0 0
IC6001 86 2.5 2.5 2.5
IC6001 87 2.5 2.5 2.5
IC6001 88 0 0 0
IC6001 89 0 0 0
IC6001 90 2.4 2.4 2.4
IC6001 91 2.5 2.5 2.5
IC6001 92 2.5 2.5 2.5
IC6001 93 0 0 0
IC6001 94 2.5 2.5 2.5
IC6001 95 2.5 2.5 2.5
IC6001 96 2.5 2.5 2.5
IC6001 97 2.5 2.5 2.5
IC6001 98 5 5 5
IC6001 99 4.9 4.9 4.9
IC6001 100 0 0 0
IC6201 1 4.9 4.9 4.9
IC6201 2 4.9 4.9 4.9
IC6201 3 0 0 0
IC6201 4 0 0 0
IC6201 5 0 0 0
IC6301 1 5 5 5
IC6301 2 0 0 0
IC6301 3 4.6 4.6 4.6
IC6301 4 5.8 5.8 5.8
REF No. PIN No. REC PB EE
IC7301 1 - - -
IC7301 2 0.3 0.3 0.3
IC7301 3 2.5 2.5 2.5
IC7301 4 0.5 0.5 0.5
IC7301 5 2.3 2.3 2.3
IC7301 6 2.3 2.3 2.3
IC7301 7 4.8 4.5 4.8
IC7301 8 - - -
IC7301 9 - - -
IC7301 10 - - -
IC7301 11 - - -
IC7301 12 - - -
IC7301 13 2.8 2.8 2.8
IC7301 14 2.7 2.7 2.7
IC7301 15 2.2 2.2 2.2
IC7301 16 - - -
IC7301 17 3.4 3.4 3.4
IC7301 18 3.4 3.4 3.4
IC7301 19 5 5 5
IC7301 20 - - -
IC7301 21 2.2 2.2 2.2
IC7301 22 3.4 3.4 3.4
IC7301 23 0 3.3 0
IC7301 24 4.9 4.9 4.9
IC7301 25 0 0 0
IC7301 26 1.7 1.7 1.7
IC7301 27 4.9 4.9 4.9
IC7301 28 1.7 1.7 1.7
IC7301 29 2.2 2.2 2.2
IC7301 30 2.1 2.1 2.1
IC7301 31 0 0 0
IC7301 32 2.2 2.2 2.2
IC7401 1 3.2 3.2 3.2
IC7401 2 0.2 0.2 0.2
IC7401 3 1.9 1.9 1.9
IC7401 4 0 0 0
IC7401 5 2.8 2.8 2.8
IC7401 6 0.2 0.2 0.2
IC7401 7 3.2 3.2 3.2
IC7401 8 5 5 5
IC7402 1 5 5 5
IC7402 2 - - -
IC7402 3 0 0 0
IC7402 4 3.4 3.4 3.4
IC7402 5 4.9 4.9 4.9
IC7402 6 - - -
IC7402 7 - - -
IC7402 8 5.8 5.8 5.8
IC7501 1 5 5 5
IC7501 2 0 0 0
IC7501 3 4.7 4.7 4.7
IC7501 4 4.9 4.9 4.9
IC7501 5 4.9 4.9 4.9
IC7501 6 4.9 4.9 4.9
IC7501 7 4.9 4.9 4.9
IC7501 8 4.9 4.9 4.9
IC7501 9 2.5 2.5 2.5
IC7501 10 2.3 2.3 2.3
IC7501 11 0 0 0
IC7501 12 2 2 2
IC7501 13 2.4 2.4 2.4
IC7501 14 0 0 0
IC7501 15 4.9 4.9 4.9
IC7501 16 4.7 4.7 4.7
IC7501 17 0 0 0
REF No. PIN No. REC PB EE
IC7501 18 1.8 1.8 0
IC7501 19 4.8 4.8 4.8
IC7501 20 4.9 4.9 4.9
IC7501 21 4.8 4.9 4.9
IC7501 22 4.9 4.9 4.9
IC7501 23 0 0 0
IC7501 24 5 5 5
IC7501 25 5 5 5
IC7501 26 3.2 3.2 3.2
IC7501 27 3.7 3.7 3.7
IC7501 28 0 0 0
IC7501 29 4.9 4.9 4.9
IC7501 30 4.9 4.9 4.9
IC7501 31 0 0 0
IC7501 32 5 5 5
IC7501 33 2.2 2.2 4.5
IC7501 34 0 0 0
IC7501 35 -3.7 -3.7 -3.7
IC7501 36 -3.7 -3.8 -3.8
IC7501 37 -5.2 -5.2 -5.2
IC7501 38 -5.2 -5.2 -5.2
IC7501 39 -5.2 -5.2 -5.2
IC7501 40 -5.2 -5.2 -5.2
IC7501 41 -2 -5 -8
IC7501 42 1.1 -5 -5
IC7501 43 1.1 -5 -5
IC7501 44 -5 -5 -5
IC7501 45 -1.9 -5 -5
IC7501 46 -5 -5 -8.1
IC7501 47 4.1 -1.1 -5
IC7501 48 -5 -5 -8.1
IC7501 49 1 -2 -5.1
IC7501 50 1 -2 -5.1
IC7501 51 -2 -2 -5.1
IC7501 52 -5 -2 -5.1
IC7501 53 -5 -5.1 -5.1
IC7501 54 -1.9 1 -2
IC7501 55 1.2 1 -5.1
IC7501 56 4.2 -2 -8.1
IC7501 57 -8.1 -8.1 -8.1
IC7501 58 3.1 3.1 3.1
IC7501 59 0 0 0
IC7501 60 5 5 5
IC7501 61 3.9 3.9 3.9
IC7501 62 4.1 4.1 4.1
IC7501 63 4.1 4.3 4.2
IC7501 64 4.8 4.8 4.8
IC7502 1 4.9 4.9 4.9
IC7502 2 4.9 4.9 4.9
IC7502 3 0 0 0
IC7502 4 - - -
IC7502 5 - - -
Q1501 E 0 0 0
Q1501 C 4.6 4.7 4.7
Q1502 E 0 0 0
Q1502 C 4.9 4.9 4.9
Q3001 E 1.6 1.6 1.6
Q3001 C 5 5 5
Q3001 B 2.2 2.2 2.2
Q3002 E 5.1 5.1 5.1
Q3002 C 5.7 5.7 5.7
Q3002 B 5.9 5.9 5.9
Q3003 E 5.1 5.1 5.1
Q3003 C 5.7 5.7 5.7
Q3003 B 5.9 5.9 5.9
REF No. PIN No. REC PB EE
Q3004 E 1.7 1.7 1.7
Q3004 C 5.1 5.1 5.1
Q3004 B 3.4 3.4 3.4
Q3901 E 3 3 3
Q3901 C 5.1 5.1 5.1
Q3901 B 3.6 3.6 3.6
Q3902 E 2.2 2.2 2.2
Q3902 C 0 0 0
Q3902 B 1.5 1.5 1.5
Q4001 E -19.4 0 0
Q4001 C 10.4 0 0
Q4001 B -28.1 0.7 0.7
Q4002 E -19.4 0 0
Q4002 C 0 0 0
Q4002 B -28.1 0.7 0.7
Q4081 E 0 0 0
Q4081 C 5.1 0.3 0.3
Q4081 B -0.6 0.3 0.3
Q4084 E 5.7 5.7 5.7
Q4084 C 5.6 0.3 0.3
Q4084 B 4.9 5.7 5.7
Q4501 E 12.4 12.4 12.4
Q4501 C 12.3 12.3 12.3
Q4501 B 11.7 11.7 11.7
Q4502 E 5.1 5.1 5.1
Q4502 C 5.7 5.7 5.7
Q4502 B 5.8 5.8 5.8
Q4801 E 0 0 0
Q4801 C 0 0 0
Q4801 B 0 0 0
Q4802 E 0 0 0
Q4802 C 0 0 0
Q4802 B 0 0 0
Q6305 E 5 5 5
Q6305 C 5.7 5.7 5.7
Q6305 B 5.8 5.8 5.8
Q7401 E 2.4 2.4 2.4
Q7401 C 0 0 0
Q7401 B 1.7 1.7 1.7
Q7402 E 0 0 0
Q7402 C 0.1 0.1 0.1
Q7402 B 0.6 0.6 0.6
QR4001 E 5.1 5.1 5.1
QR4001 C -28.1 5 5
QR4001 B 4.8 0 0
QR4082 E 0 0 0
QR4082 C 0 5.7 5.7
QR4082 B 4.8 0 0
QR4501 E 0 0 0
QR4501 C 0 0 0
QR4501 B 4.6 4.6 4.6
QR4802 E 0 0 0
QR4802 C 0 0 0
QR4802 B 0 -0.2 0
QR4804 E 5.8 5.8 5.8
QR4804 C 0 0 0
QR4804 B 5.8 5.8 5.8
QR4805 E 0 0 0
QR4805 C 0 0 0
QR4805 B 0 -0.2 0
QR4806 E 0 0 0
QR4806 C 0 0 0
QR4806 B 0 -0.2 0
QR4807 E 0.1 0.1 0.1
QR4807 C 0 0 0
REF No. PIN No. REC PB EE
QR4807 B 0 0 0
QR4810 E 0 0 0
QR4810 C 0 0 0
QR4810 B 4.8 4.8 4.8
QR4811
E 0 0 0
QR4811
C 0 0 0
QR4811
B 4.8 4.8 4.8
QR4812 E 0 0 0
QR4812 C 0 0 0
QR4812 B 4.8 4.8 4.8
QR4813 E 4.8 4.8 4.8
QR4813 C 4.8 4.8 4.8
QR4813 B 0 0 0
QR4816 E 0 0 0
QR4816 C 0 0 0
QR4816 B 0 -0.2 0
QR7401 E 36.3 36.3 36.3
QR7401 C 36.3 36.3 36.3
QR7401 B 0.1 0.1 0.1
