Panasonic EBL128 - Page 164

Panasonic Eco Solutions Nordic AB
MEW01622 Rev: - EBL128 Planning Instructions V2.0.x
162
COM loop units (output units, etc.)
Normal state
(quiescent) (mA)
Alarm state
(activated) (mA)
Addressable short circuit isolator 4370
2.2
2.2
Analog base with isolator 4313
148
1.3
1.3
Addressable multipurpose I/O unit 3361
2.2
max. 12
149
Addressable 2 voltage outputs unit 3364
150
6
6
(Addressable) External power supply 3366
15
15
Addressable siren 3377
1
13
Addressable siren with isolator 4477
1.8
10
Addressable sounder base 3378 (low/high)
2
6 / 12
Addressable sounder base 3379
0.75
2.5
151
Addressable beacon 4380
1.7
5
Light indicator 4383
1.5
4
I/O matrix board 4582
6
6
Fan control application board 4594
152
6
6
148
Detector not included.
149
Only if the input In 0 is used as a zone line input, else approx. 2.2 mA.
150
External 24 V DC power supply also required, e.g. the 3366 unit.
151
High sound output: 4.5 mA.
152
Two 4594 boards are mounted on a Fan control panel 4594. 24 V DC
power supply also required.
