Panasonic Eco Solutions Nordic AB
MEW01622 Rev: - EBL128 Planning Instructions V2.0.x
74
Figure 13. Delay time, Pulse length, Pulse off and/or De-
Activation, have to be set for the "Signal period" respectively.
For types 1 & 4 the x and y times must be equal and max. 5.6s.
For types 2 & 5 the x time must be max. 5.6s.
NOTE! There are limitations according to the following table:
