Mechanical InstallationMechanical Installation
17
16
8
9
10
11
Tapping Screw × 2
Washer × 2
Wall Bracket × 2
Mark
Attach screw but not
tighten, and align the
hole location of
battery
Tapping Screw × 2
Washer × 2
Wall Bracket × 2
Mark
Attach screw but not
tighten, and align the
hole location of
battery
Let the Platen
down
Platen (3 holes) × 2
M5*10 Screw × 6
2.2-2.5 N·m
