Panasonic EVERVOLT Smart Box - Mechanical Installation (Wall-mounting)

29
4. Mechanical Installation (Wall-mounting)
3
2 in/
8
1
2
.8
2
8 i
n
/
7
1
1
.
2
mm
Note: The distance from the Base to
the ground is decided according to
the local regulations.
Ground
3
2 i
n
/
8
12
.8
mm
Cylindrical plastic
bubble spirit level
1
2
M5
17.7 lbf.in /
2.0 N·m
Depth:
1.97 in/ 50 mm
Φ8 drill for wooden wall
Depth:
3.54 in/ 90 mm
Φ12 drill for concrete wall
mm
Mechanical Installation
28
3
Mechanical Installation
The top of the nut and contact surface of
the threads must be cleaned after locking
the nut, as well as the contact surface between
the nut and the box.
TSE-382 waterproof adhesive
or a similar performance glue.
NOTE!
Drilling a hole in the wall is required before cutting a hole in the rear.
To guarantee easy installation of the conduit and sealing with the
chassis, the hole's size must be greater than the conduit's outside
diameter.
4
Lock nut, waterproof gasket(outside),
conduit
NOTE!
Prohibit the flow of water inside the tubing water into the machine!
