Panasonic EVERVOLT Smart Box - Drill a Hole in the Back (Not Recommended)

26
5
6
Hang the EV-SB
on the bracket
Mechanical Installation
Secure the EV-SB
on the wall
• Drill a hole in the back (Not recommended)
27
2
1
Corresponds to
the holes below
the perforated paper
Mechanical Installation
26.5 lbf.in /
3.0 N·m
1
0
m
m
Drill the hole with a hole cutter.
Choose 1 inch or 2inch size
(Metal chipsmust be cleaned
after drilling)
