Panasonic EVERVOLT Smart Box - Wiring Connection on the Inverter; AC cable; PV cable

5. Wiring Connection on the Inverter
0.47 in / 12 mm
Wirings
• AC cable
12–8 AWG(for EVHB-I3)
10–8 AWG(for EVHB-I5, I6, I7)
• PV cable
10-8 AWG 0.47 in / 12 mm
Wirings
2 MPPTs(for EVHB-I3. I5, I6)
3 MPPTs (for EVHB-I7)
Wiring Connection on the Inverter
Mechanical Installation
31
30
32 i
n
/81
2
.
8
m
m
Cylindrical plastic
bubble spirit level
The steps of mounting battery modules, BMS and inverter are same as the floor-
mounting's. Please refer to Chapter 3.
3
4
A: L1 terminal B: L2 terminal C: N terminal
A,C and E: PV+ terminal
B, D and F: PV- terminal
26.5 lbf.in / 3.0 N·m
For concrete wall
x 4
x 4
For solid wood wall
M5
8.8 lbf.in /
1.0 N·m
A
B
C
D
E
F
A
B
C
