Mechanical InstallationMechanical Installation
19
18
1
• Mount the inverter
2
1
Round holes
2
M4
4.4 lbf.in /
0.5 N·m
Screw in the two M4 screws, adjust the bracket to be firmly attached on the wall
surface and tignen M4 screws
Tapping Screw × 2
Washer × 2
Wall Bracket × 2
Mark
Let the Platen
down
Step e, f, g and h
Step I
Platen (3 holes) × 2
M5*10 Screw × 6
2.2-2.5 N·m
