Panasonic EVERVOLT Smart Box - Communication Connection Steps; Between Inverters; Between Inverter and EV-SB

Diagram for communication connection steps between inverter and EV-SB
35
34
On the side of EV-SB
8-pin
Step 1
Strip Length
Conduit
0.24in./6mm
Step 2
24-18 AWG
18-16 AWG
Step 3
Step 4
On the side of inverter
Step 5
1
8
Step 5
1
8
8-pin
Step 1
Strip Length
Conduit
0.24 in / 6 mm
Step 2
24-18 AWG
18-16 AWG
Step 3
Step 4
Step 5
On the side of the first inverter
On the side of the second inverter
1
8
1
8
Step 5
Wiring Connection on the InverterWiring Connection on the Inverter
Diagram for communication connection steps between inverters
