Packing List
Packing List
Packing Lists of Battery
EV-BMS
OneBattery Module (EV-B5×1):
NOTE!
The above-mentioned accessories are only for one battery module.
Item
A
B
C
D
E
H
F
G
BracketX2
Expansion boltX4
Expansion boltX2
Fixing plate (3 holes)X2
WasherX2
Quick Installation GuideX1
M5*10 cross screwX10
Name and Quantity
Fixing plate (2 holes)X2
Description
Support battery module to be mounted on the wall
Fix the bracket
Fix the bracket
Fix the bracket
Connect two battery modules with bracket
Connect two battery modules
Fix the fixing plate
Battery moduleX1
Product
I
Guide the installation
Item
A EV-BMS
Description
User ManualX1
Guide the installation and maintenance
B
Name and Quantity
Product
A B
B C D E F
A G H I
Accessories for Both Floor and Wall Mounting (Separate Accessory Box)
Item
/ Base
Description
Name and Quantity
Product
Base for Battery:
Item
A
B
C
D
E
F
G
Transverse plateX1
Expansion screwX6
M5*8 countersunk screwX4
Adjustment screwX4
M5*20 countersunk screwX6
Name and Quantity
Self-tapping screwX6
Description
Support the base
Fix the base support in case of concrete wall
Fix the transverse plate with base support
Fix the two sides of base
Adjust the base to be leveled
Fix the base support in case of wooden wall
Base supportX2
Support the base
A B C
D E F G H
H
WasherX6
Fix the base support in case of wooden wall
